Hall Effect Split Core Type Current Transformer / Current Sensor Open Loop Device

Categories Split Core Current Sensor
Place of Origin: Jiangsu, China (Mainland)
Brand Name: chieful
Model Number: CS8000KC
MOQ: 1 Piece
Price: Negotiable
Usage: Magnetic Sensor
Theory: Hall Sensor
Output: Analog Sensor
color: black
window size: 36*140mm
weight: 1220g
Selling Units: Single item
Single package size : 26X19X17 cm
Single gross weight: 1.22 kg
Package Type: packing in bubble and carton
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Hall Effect Split Core Type Current Transformer / Current Sensor Open Loop Device

Hall Effect Split Core Type Current Transformer / Current Sensor Open Loop Device
Product Description

High accuracy

low power consumption

good linearity and strong overload capability.

Custom design in the different rated input current and the output current are available.

hall effect current sensor is an open loop device based on the measuring principle of the hall effect, with a galvanic isolation between primary and secondary circuit. It provides accurate electronic measurement of DC, AC or pulsed currents.
Electrical characteristics
TypeCS1000KCCS3000KC

CS50

00KC

CS8000KCCS10000KC
IPNPrimary nominal input current100030005000800010000A
IPMeasuring range of primary current0~±20000~±60000~±100000~±120000~±12000A
VOUTNominal output voltage4±1%V
VCSupply voltage±15(±5%)V
ICCurrent consumptionVC=±15V <20mA
VDInsulation voltageAC/50Hz/1min 5kV
εLLinearity<1%FS
VOOffset voltageTA=25℃ <±25mV
VOMResidual voltageIPN→0 <±20mV
VOTThermal drift of V0IP=0 TA=–25~+85℃ <±1mV/℃
TRResponse time≤7μs
fFrequency bandwidth(-3dB)DC~20kHz
TAAmbient operating temperature–25~+85
TSAmbient storage temperature–40~+100
RLLoad resistance≥10
StandardQ/320115QHKJ01-2010

About us

CHIEFUL offers a wide range of current and voltage transducers in the portfolio. And our transducer can be designed according to the specific demands.The company explore foreign markets actively, our products have been sold to the United Kingdom, Germany, Denmark, France, Italy, Sweden,Turkey, Israel, South Korea, India etc.

Exhibition

Logistics packaging


FAQ

Q1: Are you a factory?
A:We are a factory setted up more than 17 years and export more than 10years.

Q2: When is the delivery date?
A: 7-10 working days in general.

Q3: Could you send me a quotation?
A: Sure.

Q4: How about the after service?
A: Five years warranty.

Q5: What about the shipping package?
A: Anti-static package and carton.
