Low Noise Mems Gyro Sensor For Remote Control Helicopters

TL618D MEMS Current Electronic Gyroscope Sensor For Remote Control Helicopters

▶ KEY FEATURES

★ High performance drift stability

★ Low noise

★ Light weight

★ Long life,strong stability

★ Cost-effective

★ Excellent vibration performance

★ All solid state

★ Compact & light design

★ 4-20mA Current output

★ Wide temperature range

★ DC+9～36V power supply

★ Temperature drift< ±0.1°/sec/℃

▶ APPLICATION

★ Navigation

★ Car navigation

★ 3D virtual reality
★ Platform stability

★ Auto safety system
★ Turck-mounted satellite antenna equipment

★ Industrial control

★ Equipments

★ GPS combination

★ Camera stability

★ Robot

★ Ships electronic needle error compensation on inclined(angle rate) induction equipment

▶ GENERAL DESCRIPTION

TL618D is a gyroscope (angle rate sensor) based on the micro mechanical principle, a miniature inertial devices for mainly measuring the angular velocity of a moving object. Product internal with the silicon ultrafine precision ring sensing technology so that it has a high-performance, waterproof,anti-vibration, light weight, anti-electromagnetic interference characteristics and etc. Uninterrupted the machine with self-test technology, the filtering algorithm and the first time in the country by eliminating resonance technology to solve the influence on data because of the surrounding noise or vibration interference source to the ordinary gyroscope. TL618D add another international temperature sensor ompensation technology to solve the temperature drift impact problems,with over-temperature stability and long life characteristics etc. to realize the domestic similar products technology-leading technology.

Products with high cost-effective, small volume , is now widely used in the automotive, marine, moving objects, position control & attitude control, and other applications that require precise angle measurement occasions !

▶ TECHNICAL DATA

Shenzhen Rion Technology Co., Limited(RION for short) is a high-tech company specialized in design and manufacturing MEMS inclinometer, 3D compass. RION has excellent developing team both in software and hardware. In hardware, RION has the ability of manufacture and test advanced inertial navigation and integrated navigation system by equipment such as marble test platform, high-low temperature chamber, super low temperature chamber, single/triple axis turntable, several high precise automatic indexing table, impact-vibration table, 3 axis non-magnetic calibration bench, special vehicle carried dynamic test device and so on. In software, our engineers are composed mainly by professional postgraduates, doctors. we develop the inclinometer, 3D anti-magnet compass etc in China. RION’s business covers the newest technology, tech-equipment and aerospace equipment, new energy, IOT, energy saving and so on. RION’s products are the core parts of automation, intelligence, informationization, digitalization with wide application in engineering machinery, intelligent robot, oil drilling, coal mining, technology equipment, marine surveys, high precise mapping, new energy and so on.

RION is also honored by ISO9001 , 11 software copyright, many products national expertise report, several appearance patent, 2 patent of invention, 7 self-developed core technology.

RION is a Chinese brand with vigor and passion, forging itself to fully self-developed enterprise. Expecting promising future, RION is growing rapidly, providing the best solution in position, attitude and inertial navigation. RION rooted in China, covering the globe, and devote itself to pursuit ever more precise value in position, attitude.
