Categories | MEMS Gyroscope Sensor |
---|---|
Model Number: | TL740D-485 |
Place of Origin: | Guangdong, China |
Brand Name: | RION |
Packaging Details: | 1pcs gyro sensor in each inner box , 50pcs /ctn |
Supply Ability: | 30000 Unit/Units per Month Gyro sensor are avaliable |
Price: | $235.00/Pieces >=1 Pieces |
Certification: | CE, ISO |
MOQ: | 1 |
Payment Terms: | T/T, Paypal |
Delivery Time: | 7 days for samples |
Usage: | Position Sensor |
Theory: | Capacitance Sensor |
Output: | Digital Sensor |
Mesuring range: | Azimuth Angle (±180) |
Acquisition bandwidth: | >100Hz |
Resolution: | 0.01° |
Azimuth accuracy: | <0.1°/min |
Nonlinear: | 0.1% of FS |
Max angle rate: | ≥300 °/s |
Starting time: | 30s (Static) |
Input voltage: | DC9-36V |
Working Temp.: | -40 ~ +85℃ |
Storage Temp.: | -40 ~ +85℃ |
Company Info. |
Shenzhen Rion Technology Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
angle speed sensor single axis angle rate sensor price low drift angular sensor for AGV
Parameters | TL740D |
Mesuring range | Azimuth Angle (±180) |
Acquisition bandwidth (Hz) | >100 |
Resolution(°) | 0.01 |
Azimuth accuracy (°/min) | <0.1 |
Nonlinear | 0.1% of FS |
Max angle rate (°/s) | ≥300 |
Starting time(s) | 30(Static) |
Input Voltage(V) | +9~36V |
Current (mA) | 60(12V) |
Working Temp.(℃) | -40 ~ +85 |
Storage Temp(℃) | -40 ~ +85 |
Starting time(s) | 30(Static) |
Input Voltage(V) | +9~36V |
Current (mA) | 60(12V) |
Working Temp.(℃) | -40 ~ +85 |
Storage Temp(℃) | -40 ~ +85 |
Vibration(g) | 5g~10g |
Impact(g) | 200g pk,2ms,½sine |
Working life | 10 years |
Output rate | 5Hz,15Hz,25Hz,50Hz can set |
Output signal | RS232 or RS485 |
MTBF | ≥50000 hours /times |
Insulation resistance | ≥100 Megohm |
Impact resistance | 100g@11ms,3Times/Axis(half sinusoid) |
Anti-vibration | 10grms,10~1000Hz |
Protecting | IP67 |
Connector | matched with 1m cable |
Weight | 160g(without cable) |
TL740D-232 | RS232 output mode |
TL740D-485 | RS485 output mode |
![]() |
