| Categories | Tilt Switch Sensor |
|---|---|
| Brand Name: | BWSENSING |
| Model Number: | DIS334 |
| Place of Origin: | CHINA |
| MOQ: | 1 unit |
| Payment Terms: | T/T |
| Delivery Time: | 3-5 working days |
| Packaging Details: | BWSENSING BOX,Express package |
| Name: | Tilt Switch Sensor |
| Power voltage(V): | 9-35 |
| Operating temperature(℃): | -40-85 |
| Storage temperature(℃): | -55-100 |
| Measurement Range（°）: | ±180 |
| Accuracy（°）: | Dynamic 2°/ Static 0.1° |
| Zero temperature drift（°/℃）: | ±0.01 |
| Response frequency (Hz）: | 100 |
| Company Info. |
| Wuxi Bewis Sensing Technology LLC |
| Verified Supplier |
| View Contact Details |
| Product List |
DIS334 Single Axis Voltage Output Tilt Switch
Introduction:
DIS332 is a single axis tilt switch with a measurement range of ± 180 °. It has the advantages of high cost performance, small volume, high consistency and stability, and the working temperature reaches the industrial level - 40 ℃ - 85 ℃. The alarm threshold can be set according to the actual situation of the user. When the measured inclination is greater than the alarm threshold, the output line becomes closed (or disconnected). Built in solid-state relay, users do not need to configure the relay.
Performance Index:
| Parameter | Condition | DIS334 |
| Measurement Range(°) | ±180 | |
| Accuracy(°) | Dynamic 2°/ Static 0.1° | |
| Measurement axis | X | |
| Alarm axis | X | |
| Zero temperature drift(°/℃) | -40~85℃ | ±0.01 |
| Response frequency (Hz) | 100 | |
| Communication cable | 9-core cable, single 0.15mm² | |
| Weight (g) | About 220(Cable 1.5m,without package) |
Application:
● Hydraulic lift table
● High voltage power line tower monitoring
● Aerial work vehicle
● Cloud platform leveling
● Tilt-based
BWSENSING's Accuracy Traceability System:
Company introduction
Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast growing company established in 2010. The company was born in The Institute of Microelectronics (IME) of Peking University. We have achieved the top spot in the middle and high-end industry applications in the Chinese market.
From 2019, BWSENSING ® is approved as our global brand.With 10 years experience in the research-design-development and manufacture of a range of Inertial sensor technology, BWSENSING posses the skills, knowledge and experience to provide fully integrated OEM/ODM design and manufacturing services for Inclinometer, Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope. As the company co-founder Dr. Guangyi Shi said, we will use the Accurate and Cost-effective sensors to make a greater contribution to the global society for a better IoT world.
FAQ
Q1: Accuracy definition of products
A: RMS accuracy, the accuracy of each product can be traced.Accuracy test report can be provided if required.
Q2: How to select suitable model?
A: Users should check the following points:
a. Single or dual axis?
b. Commom protocol, Modbus or CAN?
c. Dynamic or static Application scenarios?
d. Horizontal or vertical installation?
Q3: How to purchase?
A: If you want sample, please purchase on BWSENSING online shop. We accept Paypal/TT/CC.If you purchase in bulk, it is recommended to consult the sales for the best price.
Q4: How long is the warranty period?
A: One year.
Q5: Tilt switch-how to change alarm angle?
A: User-defined settings can be made on the Beiwei host computer with RS232-USB through the reserved RS232 wire harness.
|
