| Categories | Excavator Seal Kits |
|---|---|
| Brand Name: | Caterpillar |
| Model Number: | 3508, 3508B, 3508C, 3512, 3512B, 3512C, 3516, 3516B, 3516C, 5130B, 5230, 5230B, 776C, 776D, 777, 777B, 777C, 777D, 784C, 785, 785B, 785C, 789, 789B, 789C, 789D, 793C, 793D, 854G, 992G, 994, 994D, D11N... RING |
| Certification: | 68555435543 |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Price negotiation |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 10 |
| Delivery Time: | 3-5 |
| Packaging Details: | box |
| model OEM: | 3508, 3508B, 3508C, 3512, 3512B, 3512C, 3516, 3516B, 3516C, 5130B, 5230, 5230B, 776C, 776D, 777, 777B, 777C, 777D, 784C, 785, 785B, 785C, 789, 789B, 789C, 789D, 793C, 793D, 854G, 992G, 994, 994D, D11N... RING |
| product name: | 2146066 RING-PISTON Caterpillar parts |
| cross code: | CA2146066 214-6066 2146066 |
| other name: | Piston Kit |
| sort: | Cylinder Liner |
| application: | Engine Parts |
| applicable: | Excavator Parts |
| Weight: | XX kg. |
2146066 RING-PISTON Caterpillar parts 3508, 3508B, 3508C, 3512, 3512B, 3512C, 3516, 3516B, 3516C, 5130B, 5230, 5230B, 776C, 776D, 777, 777B, 777C, 777D, 784C, 785, 785B, 785C, 789, 789B, 789C, 789D, 793C, 793D, 854G, 992G, 994, 994D, D11N... RING
Product Description
CA2146066
214-6066
2146066
GEN SET ENGINE 3508 3508B 3512 3512B 3516 3516B
GENERATOR SET 3508 3508B 3508C 3512 3512B 3512C 3516 3516B 3516C
INDUSTRIAL ENGINE 3508 3508B 3512 3512B 3516 3516B
LOCOMOTIVE ENGINE 3508B 3508C 3512 3512B 3516B 3516C
MARINE AUXILIARY 3508B 3508C 3512B 3512C 3516B
MARINE ENGINE 3508 3508B 3508C 3512 3512B 3512C 3516 3516B 3516C
MINING EXCAVATOR 5130B 5230 5230B
PETROLEUM ENGINE 3508B 3508C 3512 3512B 3512C 3516C
POWER MODULE PM3508 PM3512 PM3516 PP3516
PUMPER SPF343 SPS343 SPT343
TRACK-TYPE TRACTOR D11N D11R
TRACTOR 776C 776D 784C
TRUCK 777 777B 777C 777D 785 785B 785C 789 789B 789C 789D 793C 793D
VEHICULAR ENGINE 3508 3512
WHEEL DOZER 854G
WHEEL LOADER 992G 994 994D Caterpillar
3516C Marine Engine ML300001-UP
Information
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 335-6220 Y | [1] | CYLINDER HEAD GP | ||
| 392-0220 Y | [1] | INJECTOR GP-FUEL | ||
| 107-7330 | [1] | BEARING-CONNECTING ROD (STANDARD) | ||
| 107-7331 AB | BEARING-CONNECTING ROD (0.63-MM US) | |||
| 107-7332 AB | BEARING-CONNECTING ROD (1.27-MM US) | |||
| 107-7333 AB | BEARING-CONNECTING ROD (0.25-MM OS) | |||
| 107-7334 AB | BEARING-CONNECTING ROD (0.25-MM OS, 0.63-MM US) | |||
| 218-0826 | [1] | BEARING-MAIN (UPPER) | ||
| 218-0827 | [1] | BEARING-MAIN (LOWER) | ||
| 307-5472 | [2] | BELLOWS | ||
| 311-3548 | [1] | BELLOWS AS | ||
| 5B-0213 | [2] | BOLT (3/8-16X2.375-IN) | ||
| 7X-7925 | [4] | BOLT (7/8-14X11-IN) | ||
| 239-6808 | [4] | CLAMP (V-BAND) | ||
| 311-9236 | [1] | CLAMP-BAND | ||
| 131-0421 | [2] | FASTENER GP-CYLINDER HEAD | ||
| 7N-1961 | [1] | BOLT-12 POINT HEAD (3/4-16X8.5-IN) | ||
| 9Y-0635 | [1] | SPACER (19.35X30.18X45-MM THK) | ||
| 187-7738 | [1] | WASHER-HARD (21X36.5X3.5-MM THK) | ||
| 131-0420 | [6] | FASTENER GP-CYLINDER HEAD | ||
| (EACH INCLUDES) | ||||
| 7N-1961 | [1] | BOLT-12 POINT HEAD (3/4-16X8.5-IN) | ||
| 187-7738 | [1] | WASHER-HARD (21X36.5X3.5-MM THK) | ||
| 110-6991 | [1] | GASKET-CYLINDER HEAD | ||
| 101-1364 | [1] | GEAR AS-IDLER (69-TEETH) | ||
| 125-9751 | [1] | BUSHING | ||
| 101-1369 | [1] | GEAR-CAMSHAFT DRIVE (70-TEETH) | ||
| 101-1370 | [1] | GEAR-CRANKSHAFT (92-TEETH) | ||
| 211-7826 | [1] | LINER-CYLINDER BLOCK | ||
| 263-8955 | [1] | PIN-PISTON | ||
| 374-2082 | [1] | PISTON AS | ||
| 7C-6209 | [2] | PLATE-THRUST | ||
| 5B-7890 | [1] | PLUG-PIPE | ||
| 253-1238 | [2] | RETAINER-PIN | ||
| 144-5695 | [1] | RING-PISTON (INTERMEDIATE) | ||
| 214-6066 | [1] | RING-PISTON (TOP) | ||
| 223-6361 | [1] | RING-PISTON (OIL) | ||
| 144-0725 | [1] | ROD AS-CONNECTING | ||
| 7N-2043 | [1] | DOWEL | ||
| 7N-2405 | [4] | BOLT-CONNECTING ROD | ||
| 118-1655 | [1] | BUSHING (CONNECTING ROD) | ||
| 420-0652 | [4] | SEAL AS-WATER | ||
| 420-0653 | [4] | SEAL AS-WATER | ||
| 352-6061 | [1] | SEAL-LINER | ||
| 7N-2046 | [3] | SEAL-O-RING | ||
| 528-9753 | [1] | TURBOCHARGER GP | ||
| 5M-2894 | [2] | WASHER-HARD (10.2X18.5X2.5-MM THK) | ||
OME
| 7E539 Piston | Engine | 7E-539 | Ring | 8C5219 Seal Plain Encased Piston Rod | Cylinder Liner | 8C-5219 | 8C5219 Seal Plain Encased Piston Rod Cylinder Liner 7E-539 Engine 8C-5219 Ring 7E539 Piston |
| 1077545 Crown | Engine | 107-7545 | Ring | 2J3950 Nut Self Locking He Piston Rod | Cylinder Liner | 2J-3950 | 1077545 Crown Engine 107-7545 Ring 2J3950 Nut Self Locking He Piston Rod Cylinder Liner 2J-3950 |
| 1077791 Skirt | Engine | 107-7791 | Ring | 9N3743 Piston 2 Ring Std. 16.5:1 Cr | Cylinder Liner | 9N-3743 | 107-7791 Engine 9N3743 Piston 2 Ring Std. 16.5:1 Cr Cylinder Liner 1077791 Skirt Ring 9N-3743 |
| 1252782 Skirt | Engine | 125-2782 | Ring | 1P0734 Ring Group Piston Parts Service | Cylinder Liner | 1P-0734 | 1P-0734 Ring 1P0734 Ring Group Piston Parts Service Engine 125-2782 Cylinder Liner 1252782 Skirt |
| 1300241 Skirt | Engine | 130-0241 | Ring | 2168323 Piston As Does Not Include Rin | Cylinder Liner | 216-8323 | 2168323 Piston As Does Not Include Rin Cylinder Liner 130-0241 Engine 216-8323 Ring 1300241 Skirt |
|
Cat 336D 330D E336D Excavator Seal Kits for Boom Cylinder 525-3512 525-3497
Rsc18E1 Ring Set Piston Cylinder Liner 9T-5927 Engine Rsc-180 Ring 9T5927 Piston
9T3133 Piston Engine 9T-3133 Ring 9Y6773 Piston Body Assy Cylinder Liner 9Y-6773
2W1177 Piston Liner Kit Cylinder Liner 8J-6016 Engine 2W-1177 Ring 8J6016 Piston
7Y-1258 Engine 2255436 Kit Piston Ring Cylinder Liner 7Y1258 Piston Ring 225-5436
1W-5796 Ring 1W5796 Piston Body .040 Engine 7T-3928 Cylinder Liner 7T3928 Piston
2W1177 Piston Liner Kit Cylinder Liner 8J-6016 Engine 2W-1177 Ring 8J6016 Piston
2146066 Ring Piston Top Cylinder Liner 7T-5351 Engine 214-6066 Ring 7T5351 Piston
7J-6469 Engine 1786545 Ring Set 0.50 M Cylinder Liner 7J6469 Piston Ring 178-6545
7J5682 Piston Engine 7J-5682 Ring 1534101 Ring Piston Top Cylinder Liner 153-4101
