Categories | AGV Battery Pack |
---|---|
Brand Name: | CLF or OEM |
Model Number: | CLF-R5427 |
Certification: | UN38.3,MSDS |
Place of Origin: | Hunan, China |
MOQ: | 10 |
Payment Terms: | L/C,T/T |
Supply Ability: | 5000sets/month |
Delivery Time: | 30days |
Packaging Details: | carton box+tray |
Battery type: | LiFePO4/NMC Battery |
Battery size: | 24v 20Ah |
Rated voltage: | 25.6V |
Capacity: | 20AH |
Combination: | 8S1P |
Working voltage: | 20V-29.2V |
Charge current: | 20A |
Continouse Discharge current: | 100A |
Peak Discharge Current: | 200A |
Weight: | 3.35kg |
Size: | customized |
Application: | Electric forklift, AGV, Ice resurfacer, scooter etc. |
Warranty: | 2years |
Company Info. |
Hunan Chalong Fly Technology Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
CLF Electric hydraulic jack with lithium battery 10C high rate Discharge 24V 20AH lithium battery
Product Model
Model | Capacity | Battery type | Dimension(mm) | Weight | Shell | ||
Thickness | Width | Lenghth | (±1kg) | ||||
48V10Ah | 10Ah | NCM | 70 | 110 | 269 | 2.8kg | NO |
70 | 85 | 294 | |||||
48V20Ah | 20Ah | NCM | 138 | 110 | 269 | 5.5kg | NO |
138 | 85 | 294 | |||||
48V30Ah | 30Ah | NCM | 182 | 397 | 170 | 11.5kg | NO |
182 | 223 | 320 | |||||
48V40Ah | 40Ah | LiFePO4 | 200 | 548 | 195 | 28kg | Stainless steel |
200 | 324 | 334 | |||||
48V50Ah | 50Ah | LiFePO4 | 298 | 468 | 176 | 31kg | Stainless steel |
298 | 284 | 296 | |||||
48V60Ah | 60Ah | LiFePO4 | 247 | 612 | 195 | 35kg | Stainless steel |
247 | 356 | 334 | |||||
48V70Ah | 70Ah | LiFePO4 | 158 | 900 | 234 | 43kg | Stainless steel |
158 | 500 | 412 | |||||
48V85Ah | 85Ah | LiFePO4 | 158 | 900 | 234 | 44kg | Stainless steel |
158 | 500 | 412 | |||||
48V92Ah | 92Ah | LiFePO4 | 233 | 596 | 234 | 45kg | Stainless steel |
233 | 348 | 412 | |||||
48V100Ah | 100Ah | LiFePO4 | 198 | 676 | 260 | 48kg | Stainless steel |
198 | 388 | 464 | |||||
48V120Ah | 120Ah | LiFePO4 | 196 | 900 | 234 | 58kg | Stainless steel |
196 | 500 | 412 | |||||
48V140Ah | 140Ah | LiFePO4 | 198 | 868 | 260 | 64kg | Stainless steel |
198 | 484 | 464 | |||||
48V150Ah | 150Ah | LiFePO4 | 158 | 500 | 408 | 83kg | Stainless steel |
158 | 900 | 764 | |||||
48V175Ah | 175Ah | LiFePO4 | 231 | 996 | 234 | 77kg | Stainless steel |
231 | 548 | 412 | |||||
48V200Ah | 200Ah | LiFePO4 | 196 | 396 | 756 | 95kg | Stainless steel |
196 | 692 | 412 | |||||
48V240Ah | 240Ah | LiFePO4 | 230 | 396 | 756 | 100kg | Stainless steel |
230 | 692 | 412 |
Remark:
1. An ultra-large-capacity lithium battery pack that can be
customized to store up to 500 kilowatt hours of electricity;
2. Discharge current: 10A-400A, other current values can also be
customized;
3. The handle for weighing less than 10kg is directly above.
Handles above 10kg are in the width direction;
4. It can be equipped with RS485 or RS232 or CAN communication
protocol, which shall be subject to the actual situation;
5. The above are only some models. If you have other sizes and
requirements, please consult and ask for relevant plans.
Application
Production Details
From the battery cell to the battery pack, CLF controls every production link in strict accordance with the ISO9001 standard, arranges quality inspectors to check the process details to ensure the safety of the battery, and presents the best products to every customer.
![]() |
