Nickel Alloy 625 Seamless Tube Superior Oxidation Pitting Resistance

Categories	Nickel Alloy
Brand Name:	DELTA
Model Number:	inconel 625
Certification:	ISO
Place of Origin:	China
MOQ:	500 kgs
Price:	40-45 USD/Kg
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	3 Ton per week
Delivery Time:	5 - 12 days based on the quantity
Packaging Details:	standard packing for export
Products:	Nickel alloy Pipe
Grade:	inconel 625
Diameter:	DN10 - DN300
Length:	6m or custom cutting any length as request
Standard:	ASTM EN
Service:	Cutting
Loading Port:	Shanghai Port
Thickness:	0.5 - 40.0mm

Contact Now

Add to Cart

Company Info.

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Nickel Alloy 625 Seamless Tube Superior Oxidation Pitting Resistance

Nickel Alloy 625 Seamless Tube – Superior Oxidation & Pitting Resistance

Products Specification

Model	Nickel Tubes Pipes
Material Grade	Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc
Diameter	a) Capillary Tube Outer Diameter: 0.2mm-6.mm Welding Tube Outer Diameter: 6.mm- 840mm Seamless Tube Outer Diameter: 6mm-630mm
	b) Capillary Tube Wall Thickness: 0.02mm-2mm Welding Tube Wall Thickness: 0.5-150mm Seamless Tube Wall Thickness: 0.5-60mm
	c) Length: ≤500mm Or in coil
Tolerance	a) Outer Diameter: +/- 0.01mm
	b) Thickness: +/- 0.01mm
	c) Length: +/- 0.1mm
Surface Treatment	Polishing,Annealing, Bright, Pickling
Type	Welded,Seamless
Shape	Round,Square,Irregular
Application	medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.

Inconel 625 Pipe is a nickel chromium super alloy pipe that is made up of 58% nickel, 20% chromium, carbon, manganese, silicon, iron, sulfur, aluminum and titanium in the composition. The pipes are highly corrosion resistant. Navstar Steel is a leading manufacturer and supplier of the Inconel 625 Pipe and tubes. The material has 517MPa minimum yield strength and 930MPa minimum tensile strength.

The Alloy 625 Seamless Tubing comes in sizes ranging from 4mm to 219mm. There are welded, fabricated and LSAW pipes as well. The welded and EFW pipes range from 5mm to 1219.2mm in size. The wall thickness of the Inconel 625 Seamless Pipe ranges from 0.5mm 20mm. The pipes are specified for larger diameters with schedules ranging from 5 to 160. The pipes come in different forms such as round and hydraulic pipes. The lengths of the pipes vary as single random, double random and cut to lengths.

UNS N06625 Tube Schedules

1/8" IPS(.405"O. D.)	3 1/2" IPS( 4.000"O. D.)
SCH 40, 80	SCH 10, 40, 80, 160, XXH
1/4" IPS(.540"O. D.)	4" IPS(4.500"O. D.)
SCH 10, 40, 80	SCH 10, 40, 80, 160, XXH
3/8" IPS(.675"O. D.)	5" IPS( 5.563"O. D.)
SCH 10, 40, 80	SCH 10, 40, 80, 160, XXH
1/2" IPS(.840"O. D.)	6" IPS(6.625"O. D.)
SCH 5, 10, 40, 80, 160, XXH	SCH 5, 10, 40, 80, 120, 160, XXH
3/4" IPS(1.050"O. D.)	8 ” IPS(8.625"O. D.)
SCH 10, 40, 80, 160, XXH	SCH 5, 10, 40, 80, 120, 160, XXH
1" IPS:(1.315′O. D.)	10" IPS(10.750"O. D.)
SCH 5, 10, 40, 80, 160, XXH	SCH 10, 20, 40, 80 (.500), TRUE 80(.500)
1-1/4" IPS(1.660"O. D.)	12" IPS(12.750"O. D.)
SCH 10, 40, 80, 160, XXH	SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500)
1-1/2" IPS(1.900"O. D.)	14" IPS(14.000"O. D.)
SCH 10, 40, 80, 160, XXH	SCH10 (.188), SCH40 (.375)
2" IPS(2.375"O. D.)	16" IPS(16.000"O. D.)
SCH 10, 40, 80, 160, XXH	SCH10(.188), SCH40(.375)
2 1/2" IPS(2.875"O. D.)	18" IPS (18.000"O. D.)
SCH 10, 40, 80, 160, XXH	SCH-40 (.375)
3" IPS( 3.500"O. D.)
SCH 5, 10, 40, 80, 160, XXH

Inconel Din 2.4856 Welded Pipe Composition Standard

Grade		C	Mn	Si	Fe	S	Cr2	Al-Ti	Ni
625	min.	–	–	–	–	–	20.0	–	58.0
625	max.	0.10	0.50	0.50	5.0	0.015	23.0	0.40	–

ASME SB444 Alloy 625 Hexagonal Pipe Characteristics

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Rockwell B (HR B) max	Brinell (HB) max
Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
625	Psi – 1,35,000 , MPa -930	Psi – 75,000 , MPa – 517	42.5	–	–
