Data-Driven Decision-Making on High-Performance PCB Router Machine

Introduction

Engineered with precision and efficiency as its foundational principles, this inline automatic PCBA routing machine utilizes a jig-based system to firmly stabilize the PCBA during the automated routing process on its underside. Once routing is completed, an advanced suction nozzle mechanism is deployed to delicately lift and precisely position the PCBA, along with its jig, as a unified assembly. This revolutionary feature allows the machine to effectively separate stamp holes, curved PCBs, and various other irregularly interconnected PCB configurations, thereby optimizing production workflows and boosting overall productivity.

Features

1. Utilizing a vacuum-based system, the PCBA is meticulously picked and placed, guaranteeing accurate and reliable handling.
2. The machine executes bottom cutting operations with unparalleled precision, tailored precisely to the unique requirements of the PCBA.
3. With dual-platform cutting capability, the machine boosts productivity by enabling simultaneous or alternating cutting processes.
4. Integrated broken knife detection ensures prompt recognition of any issues, enabling swift maintenance and minimizing operational downtime.
5. The machine seamlessly integrates into automatic production lines, ensuring a smooth and efficient workflow throughout the entire process.
6. Equipped with SPC (Statistical Process Control) statistics functionality, it integrates seamlessly with ERP systems to provide insightful data on production performance, facilitating informed decision-making.
7. Optional features such as automatic tool change for added versatility, an explosion-proof vacuum cleaner for enhanced safety, and air volume monitoring to maintain optimal suction performance, further customize the machine to suit specific needs.

Technical details

Machine size

Bottom size routing and dust collector

Excellent CCD system with imaging camera, moritex lens and measurement - level light source, to support machine calibration,compensation and positioning, with great stability and anti-disturbance capacity.

Omnipotence vacuum suction chuck for picking, placing , unloading, and production.

Composite unloading system, used the ESD anti-static belt to transport the separated product on the top side, and the waster is transported on the bottom side, save much space by this method.
