Brand Name: | YUE MI |
Model Number: | M7N |
Certification: | ISO SGS |
Place of Origin: | Guangzhou, China |
MOQ: | 1/PCS |
Price: | consult |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 100/Set/Month |
Delivery Time: | 5-8 word days |
Packaging Details: | Details Carton |
Origin: | Guangzhou, China |
Extra Service: | OEM is welcome |
Item: | Mechanical seal |
Equivalent: | Burgma Nn Type M7n |
Type: | G9 |
Company Info. |
YUEMI |
Verified Supplier |
View Contact Details |
Product List |
M7N seal adopts mature sealing structure design.
Due to the wide selection of materials, it can be used in different medium conditions.
Standard modular mass production has low cost and competitive price.
DETAILS
Shaft Size | 14-100mm |
Material | Face: Carbon, SiC, TC Seat: Ceramic, SiC, TC O-rings:NBR,EPDM,FKM,Aflas,FEP,Kalrez,Chemraz etc Spring:SS304, SS316, Hastelloy C Other Metal Parts : SS304, SS316 |
Performance Capabilities | Temperature:-30°C to 200°C Pressure: Up to 12bar (unbalance type) Speed: Up to 18m/s End play/axial float allowance: ±0.1mm |
Metric Shaft Size D1 | Size Code | D3 | D7 | L1 | L4 |
14 | 0140 | 25.0 | 25.0 | 25.0 | 10.0 |
16 | 0160 | 27.0 | 27.0 | 25.0 | 10.0 |
18 | 0180 | 33.0 | 33.0 | 26.0 | 11.5 |
20 | 0200 | 35.0 | 35.0 | 26.0 | 11.5 |
22 | 0220 | 37.0 | 37.0 | 26.0 | 11.5 |
24 | 0240 | 39.0 | 39.0 | 28.5 | 11.5 |
25 | 0250 | 40.0 | 40.0 | 28.5 | 11.5 |
28 | 0280 | 43.0 | 43.0 | 31.0 | 11.5 |
30 | 0300 | 45.0 | 45.0 | 31.0 | 11.5 |
32 | 0320 | 47.0 | 48.0 | 31.0 | 11.5 |
33 | 0330 | 48.0 | 48.0 | 31.0 | 11.5 |
35 | 0350 | 50.0 | 50.0 | 31.0 | 11.5 |
38 | 0380 | 55.0 | 56.0 | 31.0 | 14.0 |
40 | 0400 | 57.0 | 58.0 | 31.0 | 14.0 |
43 | 0430 | 60.0 | 61.0 | 31.0 | 14.0 |
45 | 0450 | 62.0 | 63.0 | 31.0 | 14.0 |
48 | 0480 | 65.0 | 66.0 | 31.0 | 14.0 |
50 | 0500 | 67.0 | 70.0 | 32.5 | 15.0 |
53 | 0530 | 70.0 | 73.0 | 32.5 | 15.0 |
55 | 0550 | 72.0 | 75.0 | 32.5 | 15.0 |
58 | 0580 | 79.0 | 78.0 | 37.5 | 15.0 |
60 | 0600 | 81.0 | 80.0 | 37.5 | 15.0 |
63 | 0630 | 84.0 | 83.0 | 37.5 | 15.0 |
65 | 0650 | 86.0 | 85.0 | 37.5 | 15.0 |
68 | 0680 | 89.0 | 90.0 | 34.5 | 18.0 |
70 | 0700 | 91.0 | 92.0 | 42.0 | 18.0 |
75 | 0750 | 99.0 | 97.0 | 42.0 | 18.0 |
80 | 0800 | 104.0 | 105.0 | 41.8 | 18.2 |
85 | 0850 | 109.0 | 110.0 | 41.8 | 18.2 |
90 | 0900 | 114.0 | 115.0 | 46.8 | 18.2 |
95 | 0950 | 119.0 | 120.0 | 47.8 | 17.2 |
100 | 1000 | 124.0 | 125.0 | 47.8 | 17.2 |
We welcome you to test the quality of our products and our services
through small orders and look forward to long-term cooperation with
you next.
![]() |
