Condition: | New |
Steering: | Left |
Horsepower: | 351 - 450hp |
Emission Standard: | Euro 2 |
Brand Name: | hohan |
Place of Origin: | China |
Segement: | Heavy truck |
Market Segement: | Urban construction muck transportation |
Engine Brand: | Sinotruk |
Fuel Type: | Diesel |
Engine Capacity: | > 8L |
Cylinders: | 6 |
Gear Box Brand: | SINOTRUCK |
Transmission Type: | Manual |
Forward Shift Number: | 10 |
Reverse Shift Number: | 2 |
Maximum Torque(Nm): | 1000-1500Nm |
Dimensions (L x W x H) (mm): | 8.6x2.5x3.45m |
Cargo Tank Dimension: | 5.6x2.3x1.5m |
Cargo Tank length: | 5.3-6.2M |
Gross Vehicle Weight: | 20-25T |
Capacity (Load): | 31 - 40T |
Fuel Tank Capacity: | 300-400L |
Drive Wheel: | 6x4 |
Passengers: | 2 |
Driver's Seat: | Air suspension |
Rear Camera: | None |
Cruise Control: | Normal |
ABS(Antilock Braking System): | Yes |
ESC(Electronic Stability Control System): | Yes |
Touch Screen: | None |
Multimedia System: | Yes |
Window: | Automatic |
Air Conditioner: | Automatic |
Tire Number: | 10 |
After-sales Service Provided: | Video technical support, Overseas Call Centers, Online support, Free spare parts, Field maintenance and repair service |
Product name: | hahan N7 6x4 dump truck |
Drive type: | 6*4 Left Hand Driving |
Tire: | 12.00R20 |
Engine: | WD615.47 |
Transmission: | HW19710 |
Cab: | HW76 one sleeper |
Horse power: | 371hp |
Loading capacity: | 30-40 Ton |
Price: | $25,410.00/units 1-1 units |
MOQ: | 1 Unit |
Delivery Time: | 10 Days |
Payment Terms: | T/T |
Supply Ability: | 300unit/ Day |
Company Info. |
Dongguan Xianmang Electronic Trade Co., Ltd |
Verified Supplier |
View Contact Details |
Product List |
SINOTRUK HOHAN N7 6X4 20CBM DUMP TRUCK MODEL ZZ3255N3846B1 | |||
Body | Carriage Internal Dimensions(mm) | 5600*2300*1500 | |
Cubage (m3) | 19 | ||
Steel thickness of Carriage(mm) | Floor:8mm/Side:6mm | ||
Steel | Q235 | ||
Hydraulic Lift of Carriage | Middle Lift | ||
Weight | Kerb weight (Kg) | 12270 | |
Gross vehicle weight (Kg) | 25000 | ||
Dimension (mm) | Dimensions (mm) | Length(mm) | 8245 |
Width(mm) | 2550 | ||
Height(mm) | 3450 | ||
Wheel base (mm) | 3800+1400 | ||
Performance | Maximum driving speed (km/h) | 75 | |
Fuel consumption (1/100 km) | 38 | ||
Cab | Model | SINOTRUK H77L cab Single bunk,new type seat,adjustable steering ,air conditioner, MP3 | |
Engine | Model | WD615.47 , 371HP (Euro 2) | |
Type | 6-cylinder in line, 4-stroke, water-cooled, turbo-charged , direct
injection | ||
Maximum output Kw/r/min | 273/2200 | ||
Maximum torque N.m/r/min | 1460/1300-1600 | ||
Displacement | 9.726L | ||
Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with
80ºC opening begin, Rigid fan | |||
Transmission | SINOTRUK HW19710 transmission ,10 forward and 2 reverse, with PTO | ||
Clutch | SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with
air assistance | ||
Steering | ZF8118 Steering Gear Box ,hydraulic steering with power assistance. | ||
Front Axle | SINOTRUK HF9, Front Axle,new 9-ton front axles of equipped with
drum brakes. | ||
Rear Axles | SINOTRUK HC16, Heavy reduction drive axle,STR hub-reduction with
differential locks between wheels and axles | ||
Brake System | Service brake:dual circuit compressed air brake Parking brake (emergency brake):spring energy,compressed air
operating on rear wheels | ||
Wheels/ Tyres | 12.00R20 | ||
Electrics | Operating voltage:24V,negative grounded Starter:24V,7.5 Kw Alternator:3-phase,28V,1500 W Batteries:2x12 V,165 Ah horn,headlamps,fog lights,brake lights,indicators and reverse light | ||
Oil Tank | Square type-300L Aluminum alloy fuel tank |
Q1:How is your goods quality?A1: We ensure you that all our goods are original factory quality,
without any refit or change. It is 100% new and original. Q2. What is your payment terms ?A2: 50% T/T deposit, 50% T/T balance before shipment . Q3. How long time will you take to deliver goods to customer ?A3: Generally 30 working days , after we receive your deposits . Q4:How you can ensure you have delivered goods to customers ?A4: We will inform you goods delivery in the whole course, give you
the complete genuine shipping information details . You can also
use your own agent for shipping. Q5. How you could supply customers after sales services ?A5: We will reply you at first time and help you resolve the
problems within 24 hours . If it really need us to your local , we
will send your professional engineer to your local to help you
resolve problems without any hesitation , supply you all-around
after-sales services including machine maintenance and operation
and technical training services etc . |
![]() |
