| Categories | Electric Cargo Truck |
|---|---|
| Brand Name: | DONGFENG |
| Place of Origin: | Hubei, China |
| MOQ: | One Set |
| Price: | $33,200.00/sets 2-2 sets |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 500 sets per year |
| Delivery Time: | 45-50 working days |
| Packaging Details: | Standard Exports Packings |
| Condition: | New |
| Steering: | Left |
| Emission Standard: | EURO 5 |
| Segement: | Light truck |
| Market Segement: | Logistics transportation |
| Fuel Type: | Electric |
| Horsepower: | < 150hp |
| Forward Shift Number: | 5 |
| Reverse Shift Number: | 1 |
| Maximum Torque(Nm): | ≤500Nm |
| Size: | 5995X2180X3100(mm) |
| Cargo Tank Dimension: | 4200X2100X2100(mm) |
| Cargo Tank length: | ≤4.2m |
| Cargo Tank Type: | Van |
| Gross Vehicle Weight: | <=5000 kg |
| Capacity (Load): | 1 - 10t |
| Drive Wheel: | 4X2 |
| Passengers: | 3 |
| Driver's Seat: | Normal |
| Seat Rows: | Single row |
| Rear Camera: | Camera |
| ABS(Antilock Braking System): | Yes |
| ESC(Electronic Stability Control System): | Yes |
| Touch Screen: | Yes |
| Multimedia System: | None |
| Window: | Automatic |
| Air Conditioner: | Automatic |
| Tire Number: | 6 |
| After-sales Service Provided: | Video technical support, Online support |
| Overall dimension (mm): | 5995X2180X3100(mm) |
| cargo box size (mm): | 4200X2100X2100(mm) |
| Payload (kg): | 1445 |
| Total weight (kg): | 4495 |
| H.S CODE: | 87042100.00 |
| Company Info. |
| Ricalt Automobile Technology (Hubei) Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Total gross weight | 4495kg |
Wheelbase | 3308 mm |
Length of cargo box | 4.2m |
Peak power | 120Kw |
Maximum torque | 350N.m |
Endurance Mileage | 345Km |
Maximum speed | 90Km/h |
Cargo box volume | 18.5 CBM |
Overall dimension (mm) | 5995x2180x3100 | |
Cargo box size(mm) | 4200x2100x2100 | |
wheelbase (mm) | 3308 | |
total weight (kg) | 4495 | |
tare weight (kg) | 2920 | |
Payload (kg) | 1490 | |
Motor | ||
Fuel type | pure electricity | |
Motor brand | Suzhou Huichuan | |
Motor model | TZ230XSIN101 | |
Motor type | permanent magnet synchronous motor | |
Battery | ||
Battery model | DHYLF0802P78SA | |
Battery type | Lithium iron phosphate battery | |
Battery capacity | 79.87kWh | |
Total battery voltage | 569.4V | |
Factory standard range | 345Km | |
Charging time | 1.5/13 hours | |
|
