Long life and strong stability Gyrosocope Sensor IMU CAN2.0 gyro Sensor For Automatic Agricultural Machinery

▶ INTRODUCTION

TL725D is a gyroscope IMU specialized in navigation applications for agricultural machinery automatic driving, with built-in industrial grade three-axis gyroscope and three-axis accelerometer.

This product is precise and efficient, and is an essential component of a new generation of automated precision agricultural control.

▶ FETURES

★ Horizontal relative heading and attitude angle output

★ Real-time angular rate output

★ Long life and strong stability

★ Forward axis acceleration

★ Compact and lightweight design

★ CAN2.0A/B output optional

★ All solid state

★ Light weight

★ DC9~36V power supply

▶APPLICATION

★ Automated agricultural machinery

★ Precision agriculture

★ Combination Harvesters

★ Farming machine

▶SPECIFICATION

TL725D-C2/C3		PARAMETERS
Three-axis attitude		relative heading ±180°,Roll angle ±180°,Pitch angle ±90°
Bandwidth		>100Hz
Resolution		0.01°
Nonlinear		0.1% of FS
Gyro Range		300°/s
Zero bias instability of gyro (allan)		4.0°/h
Angle random walk coefficient (allan)		0.25 °/sqrt(h)
Three-axis accelerometer range		±4g
Accelerometer	Acceleration resolution	0.001g
	Acceleration accuracy	1mg
	Bias instability (allan)	4.5°/h
	Angular random walk coefficient (allan)	0.25°/sqrt(h)
	Zero bias stability (10s mean)	8.5°/h
Gyro	Bias instability (allan)	0.05mg
	Speed random walk coefficient (allan)	0.015m/s/sqrt(h)
	Zero bias stability (10s mean)	0.15mg
Startup time		250ms
Input voltage		+9~36V
Current		35mA(12V)
Working temp		-40 ~ +80℃
Storage temp		-40 ~ +85℃
Vibration		5g~10g
Impact		200g pk,2ms,½sine
Working life		10 years
Output frequency		5Hz,15Hz,25Hz,35Hz,50Hz,100Hz, Settable
Output signal		CAN 2.0A / CAN2.0B(Optional)
MTBF		≥50000 Hours/times
Insulation resistance		≥100 MΩ
Shockproof		100g@11ms, 3 Axial Direction (Half Sinusoid)
Anti-vibration		10grms,10~1000Hz
Protection grade		IP67
Cable		Standard 1 m 4 pin shield wire
Weight		≤160g (including 1 meter standard cable)

Shenzhen Rion Technology Co., Limited(RION for short) is a high-tech company specialized in design and manufacturing MEMS inclinometer, 3D compass. RION has excellent developing team both in software and hardware. In hardware, RION has the ability of manufacture and test advanced inertial navigation and integrated navigation system by equipment such as marble test platform, high-low temperature chamber, super low temperature chamber, single/triple axis turntable, several high precise automatic indexing table, impact-vibration table, 3 axis non-magnetic calibration bench, special vehicle carried dynamic test device and so on. In software, our engineers are composed mainly by professional postgraduates, doctors. we develop the inclinometer, 3D anti-magnet compass etc in China. RION’s business covers the newest technology, tech-equipment and aerospace equipment, new energy, IOT, energy saving and so on. RION’s products are the core parts of automation, intelligence, informationization, digitalization with wide application in engineering machinery, intelligent robot, oil drilling, coal mining, technology equipment, marine surveys, high precise mapping, new energy and so on.

RION is also honored by ISO9001 , 11 software copyright, many products national expertise report, several appearance patent, 2 patent of invention, 7 self-developed core technology.

RION is a Chinese brand with vigor and passion, forging itself to fully self-developed enterprise. Expecting promising future, RION is growing rapidly, providing the best solution in position, attitude and inertial navigation. RION rooted in China, covering the globe, and devote itself to pursuit ever more precise value in position, attitude.
