Industrial Rugged DC12V input Embedded Box Computer With M12 Connectors

Categories Embedded Industrial PC
Brand Name: ITD/OEM
Model Number: ITD-MNPC-IPxx-xxxxx
Certification: CE/ROHS/FCC
Place of Origin: China
MOQ: 1PCS
Price: TBA
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 10000 unit per month
Delivery Time: a month
Packaging Details: Foam,gift box,master carton,wooden case,pallet
CPU: Intel J1900/J4125/J6412, Inte i3/i5/i7, ARM based Android optional
Material: Die-Casting Aluminum Alloy Casing
Waterproof I/Os: 2 x COM, 2 x USB, 1 x LAN, 1x DC M12 connectors
IP rate: IP67 rated
Operating temp: -20 to 60℃
MTBF: 50000hours
Applications: pharmacy industry, food and beverage processing plants
Warranty: 2 years
Power: DC 12V input, DC 9-36V input optional
OS Support: Windows 7/10/11, Linux
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Industrial Rugged DC12V input Embedded Box Computer With M12 Connectors

Industrial Rugged DC12V Input Embedded Box Computer With M12 Connectors


ip67 rated rugged waterproof embedded box computer with m12 connectors

ITD's IP67 waterproof embedded computer is a type of computer designed to withstand exposure to water and dust. Embedded computers are often used in industrial settings, where they may be exposed to harsh environments, including exposure to water and dust. By using an IP67 waterproof embedded computer, industrial users can ensure that their computing devices are protected against these elements, reducing the risk of damage and downtime.

Applications of rugge waterproof embedded computer

  • Food and Beverage Processing
  • Pharmaceutical Manufacturing
  • Chemical Processing
  • Medical and Healthcare
  • Marine and Offshore


Specifiction of of IP67 box PC

ItemAndroid SolutionX86 Solution 1X86 Solution 2
CPUARM Quad Core Cortex-A17, 1.8GHzIntel® Celeron J1900/J4125/J6412 2.0GHzIntel® Core i3/i5/i7
ChipsetRK3288 (RK3566, RK3399 optional)Intel Bay Trail SoCIntel SoC Chipset
Memory

2GB; 4GB Optional


J1900: Dual Channel, DDR3 1333/1600MHz Memory,

Max.8GB

J4125/J6412: DDR4 SODIMM×1, Max. 8GB

4th/5th----------DDR3L SODIMM×1, Up to 8GB 6th/7th/8th/10th----DDR4 SODIMM×2, Up to 32GB
Storage16GB, 32GB/64GB Optional

J1900: 1×SATA, 1×mSATA, Default to 64GB SSD

J4125/J6412: 1×M.2 2280 NVME, 1×2.5” HDD/SSD, 1×mSATA

1 × mSATA,

1 × M.2 2280 NVME

1 × HDD/SSD

GraphicsSupports max. 4K resolutionIntel HD Graphics (By CPU)

4th~7th Gen.: Intel HD Graphics (By CPU)

8th and above.: Intel UHD Graphics (By CPU)

Default Waterproof I/O

2×USB, 1×RJ45, 1×DC12V, 1×COM

More USB/COM ports, HDMI Output, Audio, etc. optional

2×USB, 1×RJ45, 1×DC12V, 1×COM

More USB/COM ports, HDMI Output, Audio, etc. optional

2×USB, 1×RJ45, 1×DC12V ,1×COM

More USB/COM ports, HDMI Output, Audio, etc. optional

LAN1 × 10/100/1000Mbps Ethernet1 × 10/100/1000Mbps Ethernet1 × 10/100/1000Mbps Ethernet
OSAndroid 7.1/8/9/10/11Windows 7/10, Linux, Windows 11 for J4125/J6412Windows 7/10/11, Linux

GENERAL

StructureBox Structure and SurfaceAluminum Alloy, Full CNC Treated, Anodizing and Anti-scratch Treatment
ColorBlack or Silver
Mounting MethodDesktop, wall mount
Cooling SystemPassive cooling system
Indicator & ButtonPower switch, Power LED, HDD LED
Dimension222×200×54mm
Net Weight1.8kg
PowerInput VoltageDC 12V 2.0
Operation/Power Saving10~30W
Environment ConsiderationsOperating Temperature-10~60℃
Storage Temperature-20~70℃
Humidity10 ~ 95% @ 10C (No condensation)
Vibration50 ~ 500 Hz, 1.5G, 0.15mm peak to peak
Shock10 G/Peak (11 ms)
Order InformationRugged Waterproof Box Computer with RK3288/ITD-MNPC-IPAN-3288
Rugged Waterproof Box Computer with RK3566/ITD-MNPC-IPAN-3566
Rugged Waterproof Box Computer with RK3399/ITD-MNPC-IPAN-3399
Rugged Waterproof Box Computer with Intel J1900/ITD-MNPC-IPCL-J1900
Rugged Waterproof Box Computer with Intel J4125/ITD-MNPC-IPCL-J4125
Rugged Waterproof Box Computer with Intel J6412/ITD-MNPC-IPCL-J6412
Rugged Waterproof Box Computer with Intel i3/ITD-MNPC-IPI3-xxxxU
Rugged Waterproof Box Computer with Intel i5/ITD-MNPC-IPI5-xxxxU
Rugged Waterproof Box Computer with Intel i7/ITD-MNPC-IPI7-xxxxU

Display of of IP67 rugged box computer
