| Categories | 3 Phase Current Transformer |
|---|---|
| Brand Name: | WSD |
| Model Number: | WSD-717-HX |
| Place of Origin: | CHINA |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 200000/day |
| Delivery Time: | 14-21days |
| Packaging Details: | Cartons / Pallets |
| Max current: | 6-10A |
| Primary current: | 1-1.5A |
| Secondary current: | 3.3-5mAmA |
| Anti-magnetic: | Available |
| Application: | electric energy meters |
| Product name: | 3 phase transformer |
3 phase current transformer 3.3mA robbery Iron casing shielding with busbar
Suitable for high precision, small phase error requirments of three-phase electric energy meters
More space in the meter can be saved with combined current transformer
Linear output current, high precision
Encapsulated with epoxy resion,with high insulation ability
It accords with IEC60044-1 0.05 class, 0.1 class, 0.2 class
| Rated primary current | Max primary current | Rated secondary current | Turn ratio | Accuracy class | DC component | Shileding | Load resistance |
| I p(A) | I max(A) | I s(mA) | N | (%) | (%) | (T) | Rb |
| 1 | 10 | 3.3 | 1:300 | 0.02/0.05/0.1/0.2 | unavailable | 300mT | 5Ω,10Ω,20Ω |
| 1.5 | 6 | 5 | 1:300 | 0.02/0.05/0.1/0.2 | |||
| Working temperature | −40℃~ 85℃ | ||||||
| Isolation voltage | 4000Vrms, 1 Min, No breakdown, No arcing | ||||||
| Insulation resistance | ≥1000MΩ | ||||||
| Operating temperature | 50Hz~60Hz | ||||||
|
