| Categories | Single Phase Current Transformer |
|---|---|
| Brand Name: | WSD |
| Model Number: | WSD-713 |
| Place of Origin: | CHINA |
| MOQ: | Negotiable |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 200000/ day |
| Delivery Time: | 7-25days |
| Packaging Details: | cartons/pallets |
| Price: | Negotiable |
| Max current: | 40-80A |
| Primary Current: | 5 -10A |
| Accuracy class: | 0.1 |
| DC immunity: | Available |
| Application: | electricity meter |
| Product name: | single phase transformer |
Single Phase Current Transformer 5A 60A single phase electrical current transformer for electricity meter
Suitable for single-phase electricity meter as well as anti-tempering electricity meter
Compact and delicate appearance
Linear output current, high precision
Encapsulated with epoxy resion,with high insulation ability
It accords with IEC60044-1 0.05 class, 0.1 class, 0.2 class
| Rated primary current | Max primary current | Rated secondary current | Turn ratio | Accuracy class | DC component | Shileding | Load resistance |
| I p(A) | I max(A) | I s(mA) | N | (%) | (%) | (T) | Rb |
| 5 | 40 | 2 | 1:2500 | 0.1/0.2 | ±3% | unavailable | 5Ω,10Ω |
| 5 | 60 | 2 | 1:2500 | 0.1/0.2 | |||
| 10 | 60 | 4 | 1:2500 | 0.1/0.2 | ±3% | ||
| 10 | 60 | 5 | 1:2000 | 0.1/0.2 | |||
| 10 | 60 | 10 | 1:1000 | 0.1/0.2 | |||
| 10 | 80 | 5 | 1:2000 | 0.1/0.2 | |||
| Working temperature | −40℃~ 85℃ | ||||||
| Isolation voltage | 4000Vrms, 1 Min, No breakdown, No arcing | ||||||
| Insulation resistance | ≥1000MΩ | ||||||
| Operating temperature | 50~60Hz | ||||||
|
