0.2MM 0.3MM 0.5MM 1MM APET Plastic Sheet Face Shields Transparent

Categories APET Plastic Sheet
Place of Origin: Jiangsu, China
Brand Name: Jiaou
Model Number: APET sheets/rolls
Packaging Details: Sample: A4 size rigid PET with PP bag in box Sheet packing: 30kg per bag or as your requirement Pallets packing: 500- 2000kg per wooden pallet Container loading: 20 tons as normal
Supply Ability: 100 Tons Per Day Plastic
MOQ: 1000 kilograms
Price: Negociated
Certification: FDA, Reach, RoHS, ISO9001
Payment Terms: L/C, T/T
Delivery Time: To Be Negotiated
Product name: APET Plastic Sheet Face Shields
Material: GAG Sheet
Thickness: 0.18-7mm
Size: 2050MM*3050MM
Processing Service: Cutting
Surface: Glossy
MOQ: 1000kg
Color: Custom color available
Application: Shields,packaging
Characteristics: Customized design
Sample: Available
Port: Ningbo, Shanghai, Lianyungang, Zhangjiagang
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

0.2MM 0.3MM 0.5MM 1MM APET Plastic Sheet Face Shields Transparent

APET Plastic Sheet 0.2MM 0.3MM 0.5MM 1MM Transparent For Face Shields


Product Description


APET plastic sheet is a thermoplastic that can be used in a wide variety of markets in a number of different applications. APET plastic sheet offers excellent clarity, good impact strength, superior thermoforming and fabrication characteristics, and excellent resistance to chemicals.



• Outstanding thermoforming characteristics, particularly in deep draw applications
• Good impact resistance
• Allows for rigid thermoforming cycle times
• FDA compliant grades available
• Die cuts/punches easily
• Low forming temperature
• Printable
• Chemical resistant
• Self-extinguishing


Technical Data Sheet
General PropertiesValueTest MethodUnit
Density1.36ISO 1183g/cm³
Water Absorption0.25ISO 62%
FlammabilityHB / HBUL 94/
Mechanical Properties
Yield Stress85ASTM D638MPa
Elongation @ Break15ASTM D638%
Tensile Modulus of Elasticity3000ASTM D638MPa
Notched Impact Strength (Charpy)2DIN EN ISO 179kJ/m2
Ball Indentation Hardness170DIN EN ISO 2039-1MPa
Shore Hardness84DIN EN ISO 868Scale D
Thermal Properties
Melting Temperature255ISO 11357-3°C
Thermal Conductivity0.28DIN 52612-1W / (M*K)
Thermal Capacity1.1DIN 52612kJ / (kg*K)
Coefficient of Linear Thermal Expansion60DIN 5375210-6K-1
Service Temperature, Long Term-20 up to +115Average°C
Service Temperature, Short Term (Max.)180Average°C
Heat Deflection Temperature80ASTM D648°C
Electrical Properties
Dielectric Constant3.4IEC 60250/
Dielectric Dissipation Factor (50Hz)0.001IEC 60250/
Volume Resistivity10 18IEC 60093Ω*cm
Surface Resistivity10 16IEC 60093
Comparative Tracking Index600IEC 60112
Dielectric Strength20ASTM D149kV/mm

Application For APET Sheet


• Packaging containers and trays
• Thermoforming insert trays
• Clamshell
• Folding boxes
• Product displays



Package



FAQ

Q1. Are you a factory or trade company?

A: We are a professional manufacturer with 15 years of experience. If you have interests, welcome to visit our factory.


Q2. Do you provide samples? Is it free or extra?

A: Yes, we could offer the sample for free, but charge by freight collection.


Q3. How about the lead time?

A: Normal sample supply it at once. Special samples need 3 days. mass production is generally 5-10 working days after receiving your initial payment.


Q4. Do you have any MOQ limits?

A: Normal Only 1000kgs, Special colors about 5000kg.


Q5. What are your terms of payment?

A: 30% T/T in advance, balance before shipment. We accept L/C at Sight.
