DIN 933 Full Thread Hex Head Bolt Fasteners Dacromet Coating For Farming Silos

Categories Hex Head Bolt
Brand Name: FLRS or OEM
Model Number: FLRS-H052
Certification: ISO9001
Place of Origin: China
MOQ: 1000 piece
Price: 0.07-0.092
Payment Terms: T/T, L/C, Western union, paypal
Supply Ability: 100tons/month
Delivery Time: 8-25days
Packaging Details: carton/ plywood pallets
Product name: Hex. bolt
Surface: Dacromet
Standard: DIN933
Size: M10*25, M10*30
Thread: Full thread
Accessories: nut & washer
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

DIN 933 Full Thread Hex Head Bolt Fasteners Dacromet Coating For Farming Silos

Gr.10.9 Hex Head Bolt Full Thread Dacromet Coating / DIN 933 Fasteners For Farming Silos


Hexagon bolt: A type of fastener consisting of a head and a screw (a cylinder with an external thread), which needs to be matched with a nut to fasten and connect two parts with through holes.


Mon
M1.6
M1.7M2M2.3M2.5M2.6M3M3.5M4M5M6M7M8M10M12M14
P0.350.350.40.450.450.450.50.60.70.8111.251.51.752
da max22.12.62.93.13.23.64.14.75.76.87.89.211.213.715.7
e min3.413.824.324.955.455.516.016.587.668.7911.0512.1214.3818.921.124.49
k min0.981.331.281.731.581.931.882.282.683.353.854.655.156.227.328.62
k max1.221.081.521.481.821.682.122.522.923.654.154.955.456.567.688.98
r min0.10.10.10.10.10.10.10.10.20.20.250.250.40.40.60.6
s max3.23.544.5555.5678101113171922
s min3.023.323.824.324.824.825.325.826.787.789.7810.7312.7316.7318.6721.67


Dacromet is a new type of surface treatment technology. Compared with the traditional electroplating process, Dacromet is a "green electroplating".


1. Superior corrosion resistance: The thickness of the Dacromet film is only 4-8μm, but its anti-rust effect is
It is more than 7-10 times that of traditional electro-galvanized, hot-dip galvanized or paint coating methods. Standard parts and pipe joints treated by Dacromet process did not show red rust after salt spray resistance test for more than 1200h.
2. No hydrogen embrittlement: Dacromet's treatment process determines that Dacromet has no hydrogen embrittlement phenomenon, so Dacromet is very suitable for the treatment of stressed parts.
coated.
3. High heat resistance: Dacromet can resist high temperature corrosion, and the heat resistance temperature can reach above 300℃. In the traditional galvanizing process, when the temperature reaches 100 ℃, the peeling has been scrapped.
4. Good bonding force and recoating performance: Dacromet coating has good bonding force with metal substrate, and has strong adhesion with other additional coatings. The treated parts are easy to be sprayed and colored, and combined with organic coatings The force even exceeds that of the phosphating film.
5. Good permeability: Due to the electrostatic effect, it is difficult for the deep holes, slits and inner walls of the workpiece to be electroplated with zinc, so the above-mentioned parts of the workpiece cannot be protected by electroplating. Dacromet can enter these parts of the workpiece to form a dacromet coating.
6. No pollution and public nuisance: Dacromet does not produce waste water and waste gas that pollute the environment during the entire process of production, processing and workpiece coating, and does not require three waste treatment, which reduces the treatment cost.
