LDPE LLDPE Film Extruder Machine 600-1000mm 185m/Min

Name: LDPE LLDPE Film Extruder Machine 6001000mm 185mMin
Brand: haijing
Price: 7 USD

LDPE LLDPE Film Extruder Machine 600-1000mm 185m/Min

Categories	Film Extruder Machine
Brand Name:	haijing
Model Number:	HJ-1500
Certification:	CE
Place of Origin:	RUIAN
MOQ:	1 SET
Price:	7
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	88
Delivery Time:	15
Packaging Details:	WOODEN CASE
Condition:	New
Application:	Film
Plastic processed:	PE
Screw design:	Single-screw
After-sales service provided:	Engineers available to service machinery overseas
Voltage:	380V 50HZ 3Phase(Customized)

Contact Now

Add to Cart

Company Info.

Ruian Haijing Machinery Co., Ltd.

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

LDPE LLDPE Film Extruder Machine 600-1000mm 185m/Min

New Printing Film Coating Extrusion Lamination Machine with LDPE LLDPE

Product Description

Product Description:

Anchor Coating Machine was specially designed for online Film Base Lamination. No matter efficiency, preciseness and quality are are far more better than regular models. It has been widely used widly used in Safe food packaging business and medical business.

Base material can be: BOPP,BOPET,CPP,CPE,and Aluminum Foil, can accept coating material of lamination grade resin of LDPE, PP, EVA, EAA etc…And can pre-coat glue on film surface before lamination.

Product Application:

Medical, Food, Electronic Packaging Products will always require high barrier packaging, sealing and even thickness.
Normally, such business will require using Aluminum Foil, PET film, BOPP film etc, compounding them together to acheive high barrier effect. We continue our study of technology, formula and engineering skill of such business, to make sure our clients can always have better supports from us.

Model	JD-CE
Screw diameter	φ90 mm
Length diameter ratio of screw	33:1
Width of finished product	600-1000MM
Film thickness	0.01-0.10MM
Material	LDPE,LLDPE.PP
Mechanical design line speed	185M/MIN
Maximum extrusion capacity	200KG/H
Main motor power	45KW
Total power	190KW
Main unwinding diameter	≤φ600 MM
Winding diameter	≤φ800 MM
2nd unwinding diameter	≤φ500 MM
weight	12T
Dimensions	9000150003200MM
Power source	380V

Machine Highlight:
1. It can maintain a stable running of 120M/Mi. Full Automatic of Auto-Splicer, Tension Control and EPC, with high efficiency and high reliability.

2.This model is double preciseness than paper base lamination machine, no matter tension, coating variation and trimming and epc, all require as less as possible.

3. there is no certain model of this one, Almost all are specialy custermized on the base material and formula of the customer's products, and are designed with high pertinence. To make sure maximum effort of production.

4.We have full supply resources of each key parts of machine, including gears, glue coating machine, screws and T-Dies. In different brands and different applications. To make sure we can always supply the best to our clients according to their product.
