2 Phase Horizontal Decanter Centrifuge Equipment Sludge Dehydration

Good Price 2 Phase Sludge Dehydration Decanter Centrifuge Equipment

Select working parameter

Users can consider according to the physical properties, separation requirements, processing capacity, process requirements and other factors of the separated materials (suspension). Reasonable choice a good centrifuge operating parameters can make users get more satisfaction separation results and economic benefits.

Working principle

Centrifuge is consist of two rotors, one is drum the other is screw conveyor ( For short spiral).

Drum running with High-speed, the drum and slurry will rotate together and by the centrifugal force effect, this centrifugal force is larger than the weight many times, so that solid particles will be separated from the liquid, from the drum axis, then setting on the drum wall, the screw conveyor which located in the drum and rotating at the speed which lower than the speed of drum then push the solid particles to the residue discharge port.

Difference speed between outside drum and screw conveyor depends on the speed of the transmission ratio of differential and its rotation speed.

Product Description:

Decanter centrifuge is a mechanical equipment which utilize the principle of centrifugal and sedimentation and can carry out continual separate the suspend liquid with density difference.

The centrifuges which made by out factory can clarify, dehydrate and classify the suspensions with 0.002-3 mm solid-phase particles and thickness range at 0.5~40%.

The product can be classify into two type LW-counter-current and parallel-current base on its structure feature. According to feed feature, product can be divide into LW two-phase separator, LWS three-phase separator.

It is suitable for separating different feed under different process condition, and widely use in pharmaceutical, food, chemical, light industry, environmental protection industry etc…

Product Quality Certificates:

Recently years, we achieve plenty of honors and we have obtained various certifications , such as ASME U (Certificate No. : 38793) , ISO 9001:2015 (Certificate No. : CN1299-QC), ISO 14001:2015 (Certificate No.: CN1299-EC), ISO 45001:2018 (Certificate No.: CN1299-SC) , BV and CE .

Application:

Decanter centrifuge is most often used for clarification of liquid containing high concentrations of solid, removing solids from liquid. It is usually used in waste water and PVC sludge industry. And also can be used in sunflower oil, palm oil and tea industry.

Product competitive advantage:

1, Helical pusher adopts the special antifriction method: sprinkle hardness alloy or inlay hardness alloy anti-friction disk; anti –corrosion stainless steel is employed for the material of the main parts of drum, so that assure the durability and longer using lifetime of the equipment.

2, According to the operating condition’s characteristics of material, optimize the drum length-diameter raido, drum and structure of drum taper parts.

Aftersales service

1. 12 Months guarantee period from machine arriving date

2. Sufficient spare parts in stock are available.

3. Guide you do the normal maintenanc

Juneng Machinery Group is a global group company specializing in the manufacturing of filters, centrifuges, and pressure vessels. It consists of Juneng Machinery (China) Co., Ltd.,  and Wuxi Hexiang Equipment Biochemical Co., Ltd. We have large production bases in Hong Kong, Nanjing, Wuxi, and Yixing. Mainly engaged in research, development, manufacturing, and sales of filtration equipment, separation equipment, and pressure vessels, it has become a leader in the domestic filtration separation and pressure vessel industry and an important global supplier

The company is proud to be the leader in such industry with 80% domestic market share in Oils & Fats industry,Chemical industry, Pharmaceutical industry, Beverage industry, Petrol-chemical industry, and now is one of the well-known producers and suppliers in the world. Our products are also exported to clients in such countries and regions as USA,German, Korea,Japan, Pakistan, Malaysia, Singapore, Vietnam and so on.

We actively participate in various domestic and foreign exhibitions such as ACHEMA and Canton fair

In recent years, our company has introduced a series of advanced equipment including Filter, Separator, Decanter centrifuge and pump. In addition, we have obtained CE certificates, ASME U certificate and ISO 9001 certificate etc.

ASME U Certificate

The company now areas 280,000 square meters in Nangjing City and Yixing City of Jiangsu Province.We have more than 1100 people employees and equipped with over 1500 units of advanced production equipment and test instrumentation.
