| Categories | Rope Making Machine |
|---|---|
| Brand Name: | LEAP |
| Model Number: | RS |
| Certification: | CE/ISO90001 |
| Place of Origin: | CHANGZHOU,CHINA |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time: | 90 working days |
| Packaging Details: | Acceptable customization |
| Material: | PET rope |
| Yarn diameter: | 0.35mm |
| Capacity: | 100kgh |
| Technics: | High Strength |
| Strand: | 4 |
| Type: | Twisted |
| Width: | 2.6m |
| Winder: | 33 spindles |
| Company Info. |
| Changzhou Leap Machinery Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Rope Making Machine For High Strength 4 Strand Twist PET Rope
Product Description:
1. Extruder: 1 set
(1) Screw dia.: 85mm; Rotation speed: 0～80rpm,
(2) L:D: 30:1; The screw is special design for PET recylce material.
(3) Pressure feedback system can adjust the screw speed automatically.
(4) Melt filter: Melt filter changer with candles
(5) Spinneret device: 1 set
(6) Metering pump: 1 set
(7) Color doserm: 1 set
(8) Magnet device: 1 set
2. Quenching Tank:1 set
(1) The tank is made by Stainless Steel 304.
(2) The horizontal pushing structure is conveniently to disassembly the spinneret.
3. First Seven roller Stretching unit: 1 set
(1) Seven pieces variable diameter roller with hard chrome plating.
(2) Built-out oil lubrication system makes gears run steady.
4. Hot water Tank:1 set
(1) Heating power: 70KW; Electrical heating, copper heating pipe
(2) Equip two pressing roller .
5. Second seven rollers stretching unit
(1) Seven pieces variable diameter roller with hard chrome plating.
(2) Built-in oil lubrication system which makes the gears run steady.
6. Spindle winder
(1) Tapered winder
(2) Winding bobbin as per clinet's reqeust.
(3) Tesnion control by inverter.
Parameter:
| Screw diameter | Φ90mm | ||
| Raw material | PET | Filament size | 0.35mm |
| Capacity | 100Kg/H | Filament shape | round |
| Screw L:D | 30:1 | Stretching unit | 2 sets |
| Screw material | 38CrMoALA | Winder | 33 spindles |
| Max linear speed | 120m/min | Instillation power | 130Kw |
| Nozzle holes | 400 holes | Overall size | 28×2.6×2.6m |
Pictures:
|
