As100-100 Small-Size High-Precision Mems Accelerometer SPI Bus Output UAV Flight Control Inertial Navigation

As100-100 Small-Size High-Precision Mems Accelerometer SPI Bus Output UAV Flight Control Inertial Navigation


Introduction:


Gyro100-1000 is a micromechanical gyroscope with high precision and small volume based on MEMS technology. It adopts small volume ceramic package and integrates temperature compensation function. It has the advantages of high impact resistance, high precision, wide range and wide temperature range. The operating temperature range is - 40 ° C to + 85 ° C and the storage temperature is - 55 ° C to + 125 ° C.


Performance Index:


Bias stability (typical)0.5mg
Offset repeatability1mg
Partial temperature coefficient0.5mg/℃
Bias stability at full temperature (typical)11mg
Threshold/resolution0.2mg
Scale factor nonlinearity0.3% of FS
Scale factor repeatability250ppm
Scale factor temperature coefficient15ppm/℃
Start-up Time0.1s
Sampling Rate1000Samples/s
Bandwidth100Hz
Power consumption<40mW
Power supply3.3VDC
OutputSPI digital output
PackageLCC ceramics
Operating temperature-40~+85℃
Storage temperature-55~+125℃
Random vibration6g effective value(20~2KHz)
Impact resistance10000g
Dimension10*10*3.5mm
Weight<1g


Application:


● Attitude Reference System(AHRS)

● UAV flight control

● Navigation

● Acceleration measurement


BWSENSING's Accuracy Traceability System:



Company introduction

Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast growing company established in 2010. The company was born in The Institute of Microelectronics (IME) of Peking University. We have achieved the top spot in the middle and high-end industry applications in the Chinese market.

From 2019, BWSENSING ® is approved as our global brand.With 10 years experience in the research-design-development and manufacture of a range of Inertial sensor technology, BWSENSING posses the skills, knowledge and experience to provide fully integrated OEM/ODM design and manufacturing services for Inclinometer, Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope. As the company co-founder Dr. Guangyi Shi said, we will use the Accurate and Cost-effective sensors to make a greater contribution to the global society for a better IoT world.



FAQ


Q1: Accuracy definition of products

A: RMS accuracy, the accuracy of each product can be traced.Accuracy test report can be provided if required.


Q2: How to select suitable model?

A: Users should check the following points:

a. Single or dual axis?

b. Commom protocol, Modbus or CAN?

c. Dynamic or static Application scenarios?

d. Horizontal or vertical installation?


Q3: How to purchase?

A: If you want sample, please purchase on BWSENSING online shop. We accept Paypal/TT/CC.If you purchase in bulk, it is recommended to consult the sales for the best price.


Q4: How long is the warranty period?

A: One year.
