1.8 Inch 24 Pin Tft Lcd Display Colour Module 6 O'Clock 128*160 Nits Custom Panel

1.8 Inch 24pin Colour Lcd Module 6 O'clock 128*160 Nits Custom Lcd Display Panel

1. Specification

2. Description

Item Name : 1.8 Inch 24pin Colour Lcd Module 6 O'clock 128*160 Nits Custom Lcd Display Panel
Color :262K / 65K /16.7M
Contrast Ratio : 500:1
Brightness : 500 cd/m2
Outline Dimension : 34.7(W)×46.7(H)×3.5(T) mm
Active Area : 28.032(W)×35.04(H) mm
Resolution :128x160 dots
Dots Pitch : 0.219(W)×0.219(H) mm
Drive Power Supply Voltage 3.2V
Viewing Angle : 6:00
Operation Temperature -20°C ~ +70°C
Storage Temperature -30°C~ +80°C
Display Mode : TFT LCD
Support Touch panel Type : Resistive touch panel or capacitive touch panel
FPC Lenght FPC connector type
IC : ST7735
IC Packaging COG

3. Drawings

Notes:
(1) Display Type : 1.8" TFT
(2) Viewing Direction : 6:00
(3) Lcd Drive IC : ST7735S
(4) Polarizer Mode : Transmissive
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS

4. Application

5. Our Service

1.We provide one-year product after-sales guarantee service to all customers who purchase our products.
2. For any technical problems encountered by customers in the process of testing or using our products, our technical team will provide customers with remote online technical support services at any time.
3. We are a factory-type supplier with ISO certification. Our products on sale have undergone strict quality inspection and testing before shipment, and have also passed CE/ROHS certification.
4. We have a professional after-sales service team, which can provide strong guarantee and logistical technical services for your orders.

5. Replacement within 30 days after the shipment of products from us due to products' problems.

6. We have long cooperation with many shipping companies and our export volume is large. The shipping companies can offer us good discounts.

7. All goods will be inspected and tested before shipment.

8. Customer`s satisfactory is most important to us.If you have any problem or questions regarding our transaction.Please contact us by Email. It will be responded within 24 hours.

6. Products Quality Assurance

(1)High-quality raw material supplier :
after-sales guarantee and long-term stable supplier, LCD panel and Driver IC made of A-regulated raw materials.
(2)Other materials:
such as polarizers, backlight film materials, etc. We also use brand new A-regulated raw materials
(3)Strict quality control:
Through rate up to 98.5%,Customer online defect rate as low as 0.3%.
Inspection is done in FOG==>LCM==>LCM+RTP/CTP==> production online inspection ==>Q.C inspection==>aging test 4 hours with load in 60 ℃ special room (as option)==>OQC.
A product must pass 5 tests before shipment: incoming inspection, 100% online inspection, QC on-site inspection, aging test and OQC inspection, etc.

7. FAQ

Q:Can you provide OEM service?
A:yes, we can provide both OEM and ODM service,can customize products according to the drawings you supply.
Q: How can I trust your product quality?
A:We have more than 10 years experience in touch screen industry. From material purchasing to product delivery, we have own professional staff and procedures to prevent potential quality risk. Our products have been approved by ROHS.
Q: What's your after-sale service?
A: If any problems, you will get our reply within 24 hours. Solution will be offered instantly by our professional and strong technical team.
Q:What is the minimum order?
A:our company mainly deals with wholesale deals,but if you insist buying one set,welcome to take a sample for you check quality and function.
once sample is confirmed, we could allow for a small mount of orders(no quantity limitation) to be put into production and once this is confirmed, MOQ is required.
Q:How long is the warranty time for your products?
A:Normally 1 year warranty without damaged by people actions like misuse.It depends on different products.
