Model Number: | LM22-3010NA |
Type: | Inductive Proximity Sensor, Non-flush type |
Place of Origin: | Zhejiang, China |
Brand Name: | Kampa |
Usage: | Position Sensor |
Theory: | Inductance Sensor |
Output: | Analog Sensor |
Description: | Proximity Sensor |
Diameter: | LM22 |
Detection distance: | 10mm |
Output form: | DC/SCR |
Control output: | DC:200mA, SCR:400mA |
Current consumption: | (NPN/PNP)DC12V, 8mA, DC24V, 15mA; AC<10mA |
response frequency: | 400Hz / 25Hz |
Output voltage drop: | DC(NPN/PNP)<3V, DC 2-wire<3.9V; AC<10V |
Working temperature: | -25 ℃ ~ 75 ℃ |
Shell material: | Metal |
Packaging Details: | Package Weight: 0.50kg (1.10lb.) Package Size: 10x10x5cm (3.94x3.94x1.97in) |
Port: | Ningbo/Shanghai |
Supply Ability: | 100000 Piece/Pieces per Month |
MOQ: | 200 Pieces |
Price: | $5.00/Pieces 200-499 Pieces |
Company Info. |
Yueqing Kampa Electric Co., Ltd. |
View Contact Details |
Product List |
Place of Origin | Zhejiang, China |
Brand Name | Kampa |
Product name | Proximity Sensor |
Type | Inductive type |
Usage | Position Sensor |
Diameter | LM22 |
Type | Non-flush type |
Detection distance | 10mm |
Output form | DC/SCR |
Control output | DC:200mA, SCR:400mA |
Current consumption | (NPN/PNP)DC12V, 8mA, DC24V, 15mA; AC<10mA |
Response frequency | 400Hz / 25Hz |
Output voltage drop | DC(NPN/PNP)<3V, DC 2-wire<3.9V; AC<10V |
Working temperature | -25 ℃ ~ 75 ℃ |
Insulation resistance | ≥50MΩ |
Shell material | Metal |
Protection grade | IP67 |
Detection distance | 10mm | |||||
Non-flush type | DC6-36V | NPN | NO | LM22-3010NA | ||
NC | LM22-3010NB | |||||
NO+NC | LM22-3010NC | |||||
PNP | NO | LM22-3010PA | ||||
NC | LM22-3010PB | |||||
NO+NC | LM22-3010PC | |||||
2-wire | NO | LM22-3010LA | ||||
NC | LM22-3010LB | |||||
AC90-250V | SCR | NO | LM22-2010A | |||
NC | LM22-2010B | |||||
NO+NC | LM22-2010C |
![]() |
