| Categories | High Bay Motion Sensor |
|---|---|
| Brand Name: | hyanll |
| Model Number: | HNS151DHB |
| Certification: | CE RED FCC |
| Place of Origin: | China |
| MOQ: | 50 |
| Payment Terms: | T/T |
| Supply Ability: | 20000 per month |
| Delivery Time: | 3~4 weeks |
| Packaging Details: | 45*30*23cm |
| Usage: | lighting and lighting system |
| IP rating: | IP65 |
| Name: | Motion Sensor Module |
| Output: | 0~10V |
| Size: | small 50mm in diameter |
| Company Info. |
| Hynall Intelligent Control Co. Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Model name: HNS151DHB Zhaga book 18 daylight harvest max. 12m HNS151DHB
This model is a motion sensor with daylight harvest and 0-10v dimming by remote control setting.
Advantage:
1. IP65, available for wallpacks, shoeboxes and UFO highbay fixtures etc.
2. Easy and small enough to be used built-in, 50mm in diameter only. Easily changed motion sensor head
and daylight head, and remove the sensor head and put the cover cap on.
3. Daylight harvest and microwave motion sensor 2 in 1
4. Max. 12m high bay mounting height
5. Customized service: Yes
Product information:
5.8GHz C-band microwave Input voltage: 12-24V DC Input current: ≥30mA. 0~10V / PWM output signal. Max. 18m in diameter for detection range mounting height: max.12m | If the lighting fixture manufacturers / contactors do not want the sensor function, they just need to easily remove the sensor head and put the cover cap on, the fixture becomes standard non-sensor control fixture. |
“Test mode” is for testing purpose only, for users to check the
functionality and choose the desired detection range. In this mode, when used f or on/off control, after motion | Users can quit this mode by pressing“ ON/OFF”,“ Reset”,or any button of“ Hold time”. The sensor settings are changed accordingly. Test mode defaulted settings-- |
|
