| Categories | Capacitive Fuel Level Sensor |
|---|---|
| Brand Name: | Sier |
| Model Number: | SPT61 |
| Certification: | CE,RoHS |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | USD40~80/Piece |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000 pieces each month |
| Delivery Time: | 7 |
| Packaging Details: | Carton |
| Power Supply: | 11-33VDC or 12VDC |
| Max Level Range: | 1800mm(100 ....... 1800mm optional) |
| Application: | GPS or GPRS fuel tank level monitor |
| Product name: | Capacitance Level Sensor |
| Accuracy: | ≤ ±0.5%F.S |
| Protection level: | IP65(connection);IP68(Sensor) |
Fuel Tank Level Sensor For GPS Tracking
SPT61 smart capacitance Fuel Tank Level Sensor are designed for liquid level measurements where the levels are lower than 3 meter, 304/316 stainless steel allows the transmitters to be suitable for harsh environments and various measuring medium, such as oil, fuels, or other media compatible with 316 stainless steel.The user can realize the ZERO or range self-calibration with two buttons or two lead lines to meet different requirements on various complex occasions.
| Feature | Advantage | Benefit |
| The thread can be fiited with flange at the top of the sensor | For large vehicles, there is a standard size integrated structure, no need to change the oil and circuit interface, directly replace the installation | Easy installation and maintance |
| Analog signal supports local two - wire touching calibration Digital signal RS485 supports automatic computer calibration | For the calibration of differe nt media, only two key "zero" and "full Span" can be easily achieved | Easy operation and suitable for many kinds of liquid measurement |
| Customs high temperation with cooling device | allowing media temperatures of up to 300°C. | special for high temperation application |
| It can be used with GSM/GPRS/GPS module | Remote vehicles monitoring | Reduce fuel consumption operation costs prevent oil theft |
| With different kinds of oil | Diesel, gasoline vehicles are available | strong universality |
|
