| Categories | Optical Fiber Fusion Splicer |
|---|---|
| Brand Name: | Tumtec |
| Model Number: | Tumtec-83A |
| Certification: | CE/ROSH/IOS9001 |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500sets |
| Delivery Time: | 5-8 work days |
| Packaging Details: | stander packing |
| Product name: | Fiber Fusion Splicer |
| Application: | FTTH System |
| Warranty: | 3 Years |
| Splicing time: | 6 seconds |
| Heating time: | 12 seconds |
| Electrodes life: | 5000 times splicing |
| Battery: | 5200 mAh |
| Typical splice Loss: | SM:0.02dB/MM:0.01dB/DS:0.04dB/NZDS:0.04dB/G.657:0.02dB |
| Weight: | 2280G(with battery) / 1900G(without battery) |
| Electrode Lifetime: | 3000 times,replaceable |
| Model | FST-83A |
| Applied fiber category | SM/MM/DS/NZDS |
| Diameter of fiber | 0.25-3.0mm/indoor cable |
| Fiber placed&Cleaved length | Coating diameter0.125-1mm/cleave length 8-16mm |
| Splicing mode | Pre-set 41 modes,can store 100 splicing modes |
| Typical splice loss | ≥60dB |
| Lighting | 3 high-power LED white light |
| Splicing time | 6-12s |
| Estimated splice loss | Yes |
| Splicing length | 20-60mm |
| Results storages | 2000 latest records |
| Tension test | 1.5-2.0N |
| Operating condition | Altitude 0-5000m,relative humidity 0-95%,-10-50℃,15m/s max wind speed |
| Storage condition | Relative humidity 0-95%,-40-80℃,battery storage:-20~30℃ long-term |
| Fiber view&Magnification | X,Y,XY,X/Y500X Magnification |
| Host machine Size/weight | 145*165*145mm/1965g(include battery) |
| Display | 90*bi-directional view,5'high resolution display with touch screen |
| Power supply | AC input 100-240V,DC input 12-15V |
| Battery capacity | 5200mAh |
| Heating times | Typical heating more than 280 times |
| Operating method | Button/touch screen |
| Adaptive discharge | Automatic ARC calibration by air pressure and temperature |
| Electrode life | 3000ARCs |
| Terminal | Mini USD 2.0 |
|
