Firestone W01-358-9603 Industrial Air Springs GUOMAT 900400H-3 0.7Mpa Max Dia 890mm

Categories Industrial Air Springs
Brand Name: AIRSUSTECH
Model Number: 900400H-3
Certification: ISO/TS16949:2009
Place of Origin: Guangzhou, China
MOQ: 3 pieces
Payment Terms: T/T, Western Union,Paypal or Others
Supply Ability: 1000pcs/week
Delivery Time: 3-8 Working Days
Packaging Details: Strong Carton Box or as Customers Requirement
Model NO.: 900400H-3
N.W.: 25.5 Kg
Warranty: One Year
Pressure Ability: 0.2-0.8 M PA
Air Inlet: 28.5 Kg
G.W.: Black
Top Plate Diameter (Width): 830 mm
Bottom Plate Diameter (Width): 890 mm
Stroke of Rubber Bellows: 340 mm
Bumper Block: Without
Screw (Nut): M10
Trademark: GUOMAT
Transport Package: Cartons
Specification: 70*70*35 cm
Origin: China
HS Code: 8708809000
Port: Huangpu, China
Function: Reduce Vibration
Material: Rubber and Aluminum
Usage: Industrial
Load Type: Compression
Production Process: Vulcanization
Shape: Convoluted
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Firestone W01-358-9603 Industrial Air Springs GUOMAT 900400H-3 0.7Mpa Max Dia 890mm

Industrial Air Spring Firestone W01-358-9603 GUOMAT 900400H-3 At 0.7 Mpa Max Dia 890mm


Detailed Product Description:


Material:Aluminum Alloy And RubberGUOMAT:W01-M58-6984
Warranty:12 MonthsNet Weight:25.5 KG
Other Name:Industry Air Spring IsolatorPressure Ability:0.2-0.8 M Pa
Gross Weight:28.5 KGFlange Ring:With Or Without
Connection Method:Flange ConnectionFlange Ring Size:890 Mm
BOLT CIRCLE DIA:830 Mm

3B900400H-3 ndustrial Triple Convoluted Air Spring Specifications


Description Assembly
Description
Assembly Order No.
Style 348-3

Ribbed neck aluminum bead rings (equal spacing), 45 mm bolts, nuts, washers

W01-358-9603

Two Ply Bellows
Rubber bellows only
W01-358-1023

Airmount / Airstroke Actuator 348-3 STYLE AIRSPRING, TYPE 4 ALUMINIUM BEAD RINGS, 1 7/8" BOLTS, NUTS & WASHERS WO1-358-9603, Firestone AL RN B/R (EQUAL SP.) 1 7/8" BNWW .


Contitech FT 5450-44 RS UNF HP,

bellows type industrial air spring,

triple-wound,

effective area 5450cm square,

maximum stroke 44cm,

stud bolt installation,

inch seal ring,

high strength 175 PSI Max
Manufacturer: Mainland
Maximum inflation pressure
120 psi
series
RS
Bellows type
Triple convolution
weight
97 pounds
Manufacturer Part Number: 20886409


The main role of air spring hoop:

The shape of the air spring is peculiar. It is similar to the steel coil spring. However, in order to meet the various needs of the market and improve the adaptability of air spring installation and use on various equipments, the high-altitude air spring variety form Diverse, the dimensions of the air springs are also different. According to the number of “drum kits”, the high-mass air springs can be divided into one song (single), two songs (double song), three songs... up to Thirteen songs. There are a number of hoops in the middle of the air springs above the second one. What is the role of the hoop? What are the benefits of this design.
FT 5450-44 RS Details Specifications:
Maximum diameter @ 100 PSIG (MM)949.9640 pounds per square MM (lbs)31480
Maximum height (MM)490.2260 pounds per square MM (lbs)47870
Maximum stroke (MM)350.5280 pounds per square MM (lbs)64870
Minimum usable height (MM)139.7Natural frequency (@ 80 psig) (cpm)68
1 MM (lb)77000400 CPM%97
3 MM (lbs)74000800 CPM%99.3
Maximum stroke (lbs)536001500 CPM%99.8
Applicable technology?113Bolt circle diameter (MM)32.68
material4Number of bolts (per ring)40
Bead type4Design height381

Flange connection type of air spring model comparison table
GUOMAT NO.Contitech NO.GUOMAT NO.Contitech NO.
FS22-3DICRFS 22-3 DI CRFS960-12RSFS 960-12 RS
FS44-5DICRFS 44-5 DI CRFS1330-11RSFS 1330-11 RS
FS76-7DICRFS 76-7 DI CRFS1710-12RSFS 1710-12 RS
FS76-7DSCRFS 76-7 DS CRFS2870-16RSFS 2870-16 RS
FS138-8DSFS 138-8 DSFS5450-16RSFS 5450-16 RS
FS210-10DSFS 210-10 DSFD960-22RSFD 960-22 RS
FS412-10DSFS 412-10 DSFD1120-30RIFD 1120-30 RI
FS614-13DSFS 614-13 DSFD1330-25RSFD 1330-25 RS
FS816-15DSFS 816-15 DSFD1710-25RSFD 1710-25 RS
FD22-4DICRFD 22-4 DI CRFD1730-40RIFD 1730-40 RI
FD44-10DICRFD 44-10 DI CRFD2380-24RSFD 2380-24 RS
FD76-14DICRFD 76-14 DI CRFD2470-40RIFD 2470-40 RI
FD76-14DSCRFD 76-14 DS CRFD2870-30RSFD 2870-30 RS
FD138-18DSFD 138-18 DSFD5450-28RSFD 5450-28 RS
FD209-21DSFD 209-21 DSFT960-34RSFT 960-34 RS
FD210-22DSFD 210-22 DSFT1330-35RSFT 1330-35 RS
FD412-18DSFD 412-18 DSFT1710-38RSFT 1710-38 RS
FD614-26DSFD 614-26 DSFT2870-45RSFT 2870-45 RS
FD816-30DSFD 816-30 DSFT5450-44RSFT 5450-44 RS
FT22-6DICRFT 22-6 DI CR
FT44-15DICRFT 44-15 DI CR
FT76-20DICRFT 76-20 DI CR
FT76-20DSCRFT 76-20 DS CR
FT138-26DSFT 138-26 DS
FT210-32DSFT 210-32 DS
FT412-32DSFT 412-32 DS
FT614-36DSFT 614-36 DS
FT816-40DSFT 816-40 DS





W01m586984 Firestone Air Spring Guomat 3b6984 at 0.7 MPa Max Dia 715mm for Industrial Big Load Machine

W01-358-6984 321 750 970 MW01-358-6008 19 750 130 M
W01-358-7801 313 750 876W01-358-7047 25 750 352
W01-358-3006 1M1A-1 751 014W01-358-8009 314 750 942
W01-358-6985 203 750 720 MW01-358-6011 19 750 150 M
W01-358-7115 115 750 525W01-358-7080 202 750 700
W01-358-8160 128-1 750 649W01-358-6040 19-.75 750 175 M
W01-358-6107 233-2 750 867 MW01-358-7091 113-1 750 495
W01-358-7119 202 750 710W01-358-8048 352 751 007
W01-358-8161 128-1 750 648W01-358-6070 128 750 646 M
W01-358-6109 233-2 750 869 MW01-358-7092 113-1 750 496
W01-358-7139 21 750 260W01-358-8118 1T12E-3 751 565
W01-358-8165 153-2 750 744W01-358-6071 128 750 645 M
W01-358-6112 21 750 270 MW01-358-7101 113 750 450
W01-358-7143 21 750 270W01-358-8119 1T12E-3 751 560
W01-358-9004 110/70 751 550W01-358-6077 205 750 750 M
W01-358-6114 21 750 290 MW01-358-7103 113 750 460
W01-358-7145 21 750 290W01-358-8151 128 750 645
W01-358-9030 1T15M-0 751 850W01-358-6079 205 750 730 M
W01-358-6120 313 750 900 MW01-358-7110 113 750 490
W01-358-7180 22 750 310W01-358-8152 128 750 646
W01-358-9034 1T15M-0 751 855W01-358-6100 113 750 450 M
