Customize Transflective STN FSTN Material 2004 Character LCD Display Module
Product Details
1. Power supply (VDD) : +5V
2. working current: about 2mA (excluding backlight power
consumption)
3. Display content: 20 (characters)×4 (lines)
4. instruction: instruction function is strong, can be combined
into a variety of input, display, shift mode to meet different
requirements
5. It can be linked to an 8-bit CPU
6. working temperature :-20℃ ~ +70℃
7. high reliability: life of 50,000 hours (25℃)
| Name | Customize Transflective STN FSTN Material 2004 Character LCD Display Module |
| Material | STN/FSTN |
| Display Content | 20*4 DOTS |
| Operating voltage | 5.0V / 3.3V |
| Driving method | According to your request |
| Viewing angle | 6 O'clock |
| Display mode | Positive Mode |
| View Area | 123.5x43.0 mm |
| Outside Dimensions | 146.0x62.5x9.2 mm |
| Dot Size (W*H) | 0.60 mm x 0.60 mm |
| Dot Pitch (W*H) | 0.55 mm x 0.55 mm |
| IC | SPLC780C or EQV |
| Connector | Pin |
| Display Mode | Positive |
| Polarizer Type | Transflective |
| Package | COB |
| OEM/ODM | Accecpted |
| System design | Lcd module related system software and hardware design accepted |
| Warranty | 12 moths free, payed warranty lifttime |
| Backlight | White LED |
| LCD Module type | Character LCD Module |
| Sample lead time | 3-7 working days |
| Customize lead time | 15-30 working days |
| Packaging | One module in a bag, bags in small carton foam protecting, small carton in big carton |
| Cetification | ISO,SGS |
JXL-2004A is a character dot matrix liquid crystal display module, it is mainly driven by the row controller SPLC780C IC is composed of. Can complete English characters and simple Chinese characters display,
its display capacity is 20×4 (5×8 dot matrix) English characters. Main technical parameters and performance.
