| Categories | Seamless Precision Steel Tube |
|---|---|
| Brand Name: | Joyruns |
| Model Number: | EN10305-1 Mechanical steel Tube |
| Certification: | ISO9000 |
| Place of Origin: | CHANGZHOU, CHINA |
| MOQ: | 5TONs |
| Price: | Negotiable |
| Payment Terms: | TT OT 100% LC AT SIGHT |
| Supply Ability: | 1000Ton/month |
| Delivery Time: | 30DAYS |
| Packaging Details: | Exporting package/wooden box package |
| Standard: | EN10305-1 |
| Grade: | E235,E255,E355,C45E, E235C,C35E, ST35,ST45,ST37 |
| Type: | Seamless Precision steel tube for Camshaft |
| OD. Range: | 6mm – 114.3mm |
| Wall thickness: | 1mm-15mm |
| Length: | Max length 12M |
| Company Info. |
| Changzhou Joyruns Steel Tube CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
S45C/C45/CK45+N EN10305-1 Cold drawing Seamless Precision Steel Tube for Camshaft
It is Used for Automotive engine cylinder liner sleeve, motor housing, piston rod, underpin, camshaft, bearing, bushing, tie rod, axle casing, suspension parts, chassis parts, motorcycle frame, other cars parts and motorcycle parts.
We are instrumental in providing to our valuable customers excellent quality S45C Seamless Precision Tubes For Camshaft which is available with the following specification:
Standard: JIS G4051, DIN, AISI/SAE.
Material: S45C, 1045.
Delivery condition: BKS(+Sra),
Application: Used for auto parts, camshaft.
EN10305-1/EN 10297-1 Grade C45 Properties
| Steel Grade | C | Si | Mn | S | P | Cr | Ni | Cu |
| 10 | 0.08-0.13 | 0.15-0.35 | 0.30-0.60 | ≤0.030 | ≤0.030 | ≤0.20 | ≤0.25 | ≤0.25 |
| 1010 | 0.08-0.13 | 0.15-0.35 | 0.30-0.60 | ≤0.050 | ≤0.040 | ≤0.20 | ≤0.25 | ≤0.25 |
| STKM11A | ≤0.12 | ≤0.35 | ≤0.60 | ≤0.040 | ≤0.040 | |||
| St37 | ≤0.17 | 0.17-0.37 | 0.35-0.65 | ≤0.020 | ≤0.025 | ≤0.25 | ≤0.25 | ≤0.20 |
| St35 | ≤0.17 | ≤0.35 | ≤0.40 | ≤0.025 | ≤0.025 | |||
| E215 | ≤0.10 | ≤0.05 | 0.7 | ≤0.025 | ≤0.025 | |||
| 20 | 0.17-0.23 | 0.17-0.37 | 0.35-0.65 | ≤0.035 | ≤0.035 | ≤0.25 | ≤0.30 | |
| STKM12A | ≤0.20 | ≤0.35 | ≤0.60 | ≤0.20 | ≤0.040 | ≤0.040 | ||
| STKM12B | ||||||||
| STKM12C | ||||||||
| STKM13A | ≤0.25 | ≤0.35 | 0.30-0.90 | ≤0.20 | ≤0.040 | ≤0.040 | ||
| STKM13B | ||||||||
| STKM13C | ||||||||
| 1020 | 0.18-0.23 | 0.30-0.60 | ≤0.050 | ≤0.040 | ||||
| S20C | 0.18-0.23 | 0.15-0.35 | 0.30-0.60 | ≤0.030 | ≤0.030 | ≤0.20 | ≤0.20 | ≤0.20 |
| St45 | ≤0.21 | ≤0.35 | ≥0.40 | ≤0.025 | ≤0.025 | |||
| E235 | 0.17-0.22 | ≤0.35 | ≤0.40 | ≤0.025 | ≤0.025 | |||
| 45 | 0.42-0.50 | 0.17-0.37 | 0.50-0.80 | ≤0.035 | ≤0.035 | ≤0.25 | ≤0.25 | ≤0.25 |
| 1045 | 0.43-0.50 | 0.17-0.37 | 0.50-0.80 | ≤0.045 | ≤0.045 | ≤0.40 | ≤0.40 | ≤0.10 |
| C45 1.0503 | 0.42-0.50 | ≤0.40 | 0.50-0.80 | ≤0.045 | ≤0.045 | ≤0.40 | ≤0.40 | ≤0.10 |
Delivery condition
C : Cold drawn/hard BK
LC: Cold drawn/soft BKW
SR: Cold drawn/stress relieved BKS
A: Annealed GBK
N: Normalized NBK
QT: Quench/tempered* QT
|
