Home > Other Machinery & Industry Equipment >

GB T4207 3A 0.5M3 Electronic Leakage Tracking Tester

Categories Flammability Test Apparatus
Brand Name: AISRY
Model Number: AISRY-5769
Certification: ISO
Place of Origin: China
MOQ: 1 set
Price: Negotiable
Payment Terms: T/T, Western Union
Supply Ability: 200 sets per month
Delivery Time: 15 work days
Packaging Details: Standard export wooden case
Power: Electronic
Application: ≥0.5 cubic meters
Standard: GB/T4207
Surface force: 1.0 ± 0.05N
Test voltage: 100 ~ 600V
Two electrode distance: 4.0mm
Drip device: drip interval can be set arbitrarily
Warranty: 1 Year
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

GB T4207 3A 0.5M3 Electronic Leakage Tracking Tester

High Quality Leakage Tracking Tester Price


Application:The leakage tracking tester meets the GB/T4207 test standard. A rectangular platinum electrode was used, and the force of the two poles on the sample was 1.0 N; 0.05 N, respectively. The applied voltage is adjustable between 100 and 600V (48-60Hz), and the short-circuit current is 1.0; 0.1A, the voltage drop should not exceed 10%. When the short-circuit leakage current is equal to or greater than 0.5A in the test circuit, the time is maintained. 2 seconds, the relay is activated, the current is cut off, indicating that the test piece fails. The time constant of the drip device is adjustable, and the amount of drip is controlled to be 44 to 50 drops/cm3 and the time interval between drops is 30 seconds.



Parameter:

surface force1.0 ± 0.05N
test voltage100 ~ 600V
the maximum test current3A
two electrode distance4.0mm
drip devicedrip interval can be set arbitrarily
Test chamber volume0.5M3
Size(L*W*H) 60x95x90cm
box material

electrostatic paint and mirror stainless steel


Quality GB T4207 3A 0.5M3 Electronic Leakage Tracking Tester for sale
