| Categories | Seamless Drill Pipe |
|---|---|
| Brand Name: | New-Era |
| Model Number: | BQ,NQ,HQ,PQ |
| Certification: | ISO9001/TS16949 |
| Place of Origin: | China |
| MOQ: | 500kg |
| Price: | Negotiation |
| Supply Ability: | 2000tons per month |
| Delivery Time: | 45 days |
| Packaging Details: | Anti-rusty oil protected,Bundles packing with plastic bags wrapped |
| Steel Grade: | 4130+SR/SAE1541/4130+QT/XJY850/XJY750 |
| Size: | 55.50x46.5 69.85x60.33 88.90x77.80 114.3x101.60 |
| Threaded: | Ends without thread |
| Surface: | Black phosphated |
| Materials: | Seamless cold drawn steel pipes |
| Casing: | AW, BW, NW, HW, HWT, PW |
| Application: | Geological drilling |
| Company Info. |
| NEW-ERA STEEL TUBE TECHNOLOGY CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
Seamless cold drawn alloy steel pipes for wire-line drill rods sizes AQ BQ NQ HQ PQ SQ by SAE/AISI4130 steel tubes
Technical Parameters:
| No. | Std.Sizes | Lengths (m) | OD*WT (mm) | Steel Grade | Depth(m) |
| 1 | AQ(AWL) | 1.5 | 44.5*4.8 | 4130+QT/SR | 300 |
| 2 | AQ(AWL) | 3 | 44.5*4.8 | 4130+QT/SR | 300 |
| 3 | BQ (BWL) | 1.5 | 55.6*4.8 | 4130+QT/SR | 600 |
| 4 | BQ (BWL) | 3 | 55.6*4.8 | 4130+QT/SR | 1200 |
| 5 | NQ (NWL) | 1.5 | 69.9*5.0 | 4130+QT/SR | 600 |
| 6 | NQ (NWL) | 3 | 69.9*5.0 | 4130+QT/SR | 1200 |
| 7 | HQ (HWL) | 1.5 | 88.9*5.6 | 4130+QT/SR | 600 |
| 8 | HQ (HWL) | 3 | 89.9*5.6 | 4130+QT/SR | 1200 |
| 9 | PQ (PWL) | 1.5 | 114.3*6.3 | 4130+QT/SR | 600 |
| 10 | PQ (PWL) | 3 | 114.3*6.3 | 4130+QT/SR | 1200 |
| 11 | SQ | 1.5 | 139.7*7.1 | 4130+QT/SR | 300 |
| 12 | SQ | 3 | 139.7*7.1 | 4130+QT/SR | 600 |
Description:
COLD DRAWN SEAMLESS ALLOY STEEL TUBES
STEEL GRADE: SAE/AISI4130
SPECIFICATIONS: ASTM A519 WITH FOLLOWING REQUIREMENTS.
MECHANICAL PROPERTIES
| Tensile Min | 725MPa |
| Yield Min | 620MPa |
| Elongation (50.8mmG.L) | Min 15% |
| Hardness | 230-280 HB |
| Condition | Stress relieved. |
| Straightness better than: | 1 in 2000 MAX (1MM DEVIATION IN 2000MM) |
| Eccentricity (Max) | 5% |
| Grain size | ≥ 9 according to ASTM E112 |
| Residual Hoop stress | <80Mpa according to ASTM E1928-99 |
DIMENSION AND TOLERANCES (IN MM)
| SR.NO. | OUTSIDE DIA | TOLERANCE | INSIDE DIA | TOLERANCE | WT | LENGTH (+5/-0) |
| 1 | 55.56 | +0.18/-0 | 46.20 | +0/-0.18 | 4.68 | 3070 |
| 2 | 69.85 | +0.20/-0 | 60.32 | +0/-0.20 | 4.765 | 3070 |
| 3 | 88.90 | +0.25/-0 | 78.00 | +0/-0.25 | 5.45 | 3070 |
NON-DESTRUCTIVE TEST
Eddy Current Examination according to ASTM E309shall be applied on all tubes using External Longitudinal notch with depth of no more than 7.5% of wall thickness (maximum notch depth 0.80mm and minimum notch depth 0.30mm) , 0.30mm maximum width and 25mm maximum length, made from the same chemistry and size of tubing.
SURFACE CONDITION
The tubes must have smooth surface
