| Categories | Fanless Box PC |
|---|---|
| Brand Name: | Yanyue |
| Model Number: | MIS-8101 |
| Certification: | CE, FCC |
| Place of Origin: | Guangdong, China |
| MOQ: | Negotiation |
| Price: | Negotiation |
| Payment Terms: | T/T |
| Supply Ability: | motherboard 100000 pieces / month ; IPC 5000 sets / month |
| Delivery Time: | According to Quantity |
| Packaging Details: | Wooden Box |
| Name: | Embedded Industrial PC |
| Hard disk rack: | 1 hard disk rack, supporting 1 2.5 inch hard disk |
| Adapt motherboard: | Dedicated motherboard |
| CPU/GPU: | Intel 1037U |
| Memory: | 4G DDR3 |
| Hard disk: | 64G MSATA |
| Company Info. |
| Shenzhen Yanyue Technology Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Features:
■ All-aluminium toothed fan-free design, fully sealed
■ Modular Wireless Material Design
■ Soldered on board 1037U CPU
■ 2LAN 6 CON 6 USB
■ Support MSATA + 2.5 inch dual hard disk
■ Supporting VGA+HDMI Independent Dual Display
| Specification parameters | Optional configuration | |||||||
| Chassis | All-aluminium toothed chassis, sandblasted titanium oxide ash | Other colours can be customized | ||||||
| Front | Power switch; Power/HDD/LAN1/LAN 2 indicator; Mic in+Line out; PS/2; 2COM RS232; 5USB2.0 | |||||||
| Back | DC12-24V input; VGA + HDMI display; 1USB; 2RJ45 Gigabit Network port; 3RS232/422/485 + 1RS232/485 serial port | |||||||
| Hard disk rack | 1 hard disk rack, supporting 1 2.5 inch hard disk | |||||||
| Adapt motherboard | Dedicated motherboard | |||||||
| CPU/GPU | Intel 1037U | |||||||
| Memory | 4G DDR3 | Optional 8G DDR3 notebook memory | ||||||
| Hard disk | 64G MSATA | Optional 32G/64G/256G Msata solid state hard disk; support 2.5 inch solid state hard disk and mechanical hard disk | ||||||
| Size | 246*209*63mm | Net/Gross Weight | 2.5/3KG | |||||
| Industrial Power Supply | Standardized 12V@5A adapter | |||||||
| Installation mode | Bracket installation | |||||||
| Work and Environment | ||||||||
| Working temperature | 0～60℃ | Storage temperature | -40～75℃ | Environmental humidity | 0~90% air humidity, no condensation | |||
| Vibration | 5-17Hz/1.0mm amplitude, 17-200Hz/1.0g acceleration | |||||||
| EMC | GB9254-2008 class A | Shock | 10g acceleration, 11ms duration | |||||
FAQ
1.Q: What's the Minimum Order Quantity(MOQ)?
A: Just 1 piece is OK.
2.Q: Are you a factory or a trading company?
A: We are one of the professional computer manufacturers located in Shenzhen, China.
3.Q: What about the after-service?
A: Two-year warranty except human error. As for the following 2 years, we can repair it for free, but charge for parts is needed. please contact us at any time when necessary. We besides our professional technicians are at your service.
4.Q: Can you provide DIY/OEM/ODM service?
A: Yes, please advise the CPU, memory, SSD or HDD, WIFI, interface ports and OS, the package box and housing(outer shell)as you wish, prices will be varied according to the quantity and specification.
|
