Worm Reducer Horizontal Mitering Bandsaw , Powerful Automatic Metal Saw
Copper winding based motor adopted for the precision speed reducing system ,the rational design ensure stability and durability of saw . Band saw’s speed reducing system , a ll transmission parts with strict processing technology , ensure running stability ,cutting efficiency improve as well .
New type speed reducing system ,adopted quality worm wheel shafts, driving gear , precision balancing treatment ,vibration reduced to the lower limit . it’s possible to adjust the balanced hydraulic cylinder and precision hydraulic value to suit the ideal cutting state saw blade runs much more stable , as a result ,the lifespan of band saw blade extended .
Life-time Maintenance ,Free Training
Quality warrant 365 days , usage assured .
Advantages
1. Worm reducer . optional gear reducer .
2. Hydraulic feed saw frame ,infinitely variable feed rate
3. Rotate the saw frame clocking for miter cutting
4. Hydraulic vise and manual handwheel for material clamping ,convenient operation
5. Optional :indined saw frame for structural steel cutting .
| MODLE | GS-4025-L | ||||
| Cutting capacity (mm) | Cutting angle | 90° | 45° | 60° | |
| 280 | |||||
| 220(H)*650(W) | 220(H)*300(W) | 220(H)*180(H) | |||
| Blade speed (m/min) | 22.48.70 | ||||
| Blade size (mm)*(L)*(W)*(H) | 4235*34*1.1 | ||||
| Workpiece clamping (Hydraulic ) | Hydraulic | ||||
| Blade tensioning (Manual) | Hand movement | ||||
| Worktable height (mm) | 720 | ||||
| Main drive structure (Worm) | Turbine | ||||
Motor Power | Main (KW) | 3 | |||
| Hydraulic (KW) | 0.42 | ||||
| Coolant (KW) | 0.09 | ||||
| Oil Volume | Hydraulic oil (L) | 60 | |||
| Coolant(L) | 60 | ||||
| Size (mm) (L)*(W)*(H) | 2105*1250*1500 | ||||
| MODLE | GY5390/200 | GY5340/150 | ||
| Cutting capacity (mm) | Height | H900 | H400 | |
| Throat depth | W1000 | W400 | ||
| Stroke (mm) | 2000 | 1500 | ||
| Blade speed (m/min) | 20-80stepless speed regulation | 22.48.70 | ||
| Blade size (mm)*(L)*(W)*(H) | 677*54*1.6 | 3720*34*1.1 | ||
| Blade tensioning (Manual) | Hand movement | Hand movement | ||
| Main drive structure (Worm) | Gear | Gear | ||
Motor Power | Main (KW) | 7.5 | 3 | |
| Hydraulic (KW) | 1.5 | 0.042 | ||
| Coolant (KW) | 0.12 | 0.09 | ||
| Oil Volume | Hydraulic oil (L) | 60 | 60 | |
| Coolant(L) | 60 | 60 | ||
| Size (mm) (L)*(W)*(H) | 4300*2300*3100 | 2510*1350*2000 | ||
|
