Categories | Galvanized Razor Wire |
---|---|
Brand Name: | Taiye |
Model Number: | R-24 |
Certification: | ISO9001 ISO140001 |
Place of Origin: | ANPING CHIINA |
MOQ: | 1Ton |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 20 tons per day |
Delivery Time: | 3-7 days |
Packaging Details: | Inner waterproof paper with woven bag outside, 50 coils be a bundle. |
Material: | Galvanized,iron,stainless steel,PVC Coated |
Inner wire Dia: | 2.5-2.7mm |
Razor Thickness: | 0.6±0.05mm |
Razor Barb Length: | 10-65mm |
Razor Barb Spacing: | 26-100mm |
Razor Barb Width: | 13-32mm |
Razor Type: | Cross Razor or Single Razor |
Manufacturer: | Yes |
Price: | To be negotiated |
Single loop rust proof galvanized black annealed wire razor barbed wire
1.Common specifications
Specification | Thickness (mm) | Wire Dia. (mm) | Barb Length (mm) | Barb Width (mm) | Barb spacing (mm) |
BTO-10 | 0.5±0.05 | 2.5mm±0.1 | 10±1 | 13±1 | 26±1 |
BTO-12 | 0.5±0.05 | 2.5mm±0.1 | 12±1 | 15±1 | 26±1 |
BTO-18 | 0.5±0.05 | 2.5mm±0.1 | 18±1 | 15±1 | 33±1 |
BTO-22 | 0.5±0.05 | 2.5mm±0.1 | 22±1 | 15±1 | 34±1 |
BTO-28 | 0.5±0.05 | 2.5mm±0.1 | 28±1 | 15±1 | 45±1 |
BTO-30 | 0.5±0.05 | 2.5mm±0.1 | 30±1 | 18±1 | 45±1 |
CBT-60 | 0.5±0.05 | 2.5mm±0.1 | 60±2 | 32±1 | 100±2 |
CBT-65 | 0.5±0.05 | 2.5mm±0.1 | 65±2 | 21±1 | 100±2 |
Concertina Coil Specification | |||||||
Coil Diameter | 300mm | 450mm | 730mm | 730mm | 980mm | 980mm | 1250mm |
(12inch) | (18inch) | (28inch) | (36inch) | (36inch) | (36inch) | (50inch) | |
Recommended Stretch Length | 4m | 10m | 15-20m | 10-12m | 10-15m | 8m | 8m |
Coil Diameter When Stretched | 260mm | 400mm | 600mm | 620mm | 820mm | 850mm | 1150mm |
Spiral Turns Per Coil | 33 | 54/55 | 54/55 | 54/55 | 54/55 | 54/55 | 54/55 |
Clips Per Spiral | 3 | 3 | 3 | 5 | 5 | 7 | 9 |
Outside Dia. | No.of Loops | Standard Length per Coil | Typs | Notes |
300mm | 33 | 4-5m | CBT-60.65 | Single coil |
450mm | 33 | 7-8m | CBT-60.65 | Single coil |
500mm | 56 | 12-13m | CBT-60.65 | Single coil |
700mm | 56 | 13-14m | CBT-60.65 | Single coil |
960mm | 56 | 14-15m | CBT-60.65 | Single coil |
450mm | 56 | 8-9m | BTO-10.12.18.22.28.30 | Cross type |
500mm | 56 | 9-10m | BTO-10.12.18.22.28.30 | Cross type |
600mm | 56 | 10-11m | BTO-10.12.18.22.28.30 | Cross type |
600mm | 56 | 8-10m | BTO-10.12.18.22.28.30 | Cross type |
700mm | 56 | 10-12m | BTO-10.12.18.22.28.30 | Cross type |
800mm | 56 | 11-13m | BTO-10.12.18.22.28.30 | Cross type |
900mm | 56 | 12-14m | BTO-10.12.18.22.28.30 | Cross type |
960mm | 56 | 13-15m | BTO-10.12.18.22.28.30 | Cross type |
980mm | 56 | 14-16m | BTO-10.12.18.22.28.30 | Cross type |
2.Product introduction
Material: low carbon steel wire, stainless steel wire, iron wire, galvanized steel wire, PVC coated steel wire, PVC coated iron wire in blue, yellow,green and other colors.
Assortment:
Electro Barbed Wire
Hot Dipped Barbed Wire
PVC Barbed Wire
Feature:
Aesthetic appearance and protective excellent performance, performance, easy to install, high safety factor, many tricks, and a good deterrent effect, corrosion resistance, aging resistance, sunshine resistance and weather resistance.
Specifications:
IOWA type, 2 strands, 4 points. Barbs' distance 3-6 inches (Tolerance +- 1/2”)
Crossed razor barbed wire/ single coil razor barbed wire/ straight razor barbed wire/ Razor Wire Mesh Fence
Normal package: 4-15kg per coil (different lengths and outside diameters can be ordered per coil ) Moisturer-proof paper coated and woven bags outside. Some customers need paper carton packaging, 5 coils per carton, weight 25-30kg.
