| Categories | Carbide End Mill |
|---|---|
| Brand Name: | SUPAL |
| Place of Origin: | Changzhou,Jiangsu,China |
| MOQ: | 5PCS |
| Payment Terms: | T/T |
| Supply Ability: | 10000000PCS |
| Delivery Time: | 7-15Days |
| Packaging Details: | 1.One piece in a platic pipe, 10 pieces per group. 2.Use the air bubble paper to encase the plastic pipe. 3.Put the goods encased with air bubble paper in the carton. 4.Other packing will be accept according to your needs. |
| Usage: | Metal Drilling |
| Hardness: | 45HRC,55HRC,65HRC |
| Coating: | TiAlN AlTiN TiAlCrN TiAIN |
| Suitable for: | Cast Iron, Carbon Steel, Mould Steel, Tool Steel |
| Service: | OEM |
| Transport: | UPS/Fedex/DHL/TNT/EMS/Sea |
| Price: | To be negotiated |
| Model Number: | OEM |
| Company Info. |
| Supal (Changzhou) Precision Tools Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
1.Standard size 4mm,6mm,8mm,10mm,12mm,14mm,16mm,18mm,20mm
2.High Precision,Good Surface & Performace
Product Name | Efficiency coating tungsten cnc carbide chamfer mill countersink
drill bit |
Material | stainless steel/steel |
Precision | High Precision |
Standard | ISO |
OEM | Accept |
Suitable for | Cast Iron, Carbon Steel, Mould Steel, Tool Steel |
Controlling Mode | CNC |
Used | CNC Lathe machinery |
| Super Raw Material | ||||
| Item Grade | HRC45 | HRC55 | HRC60 | HRC65 |
| (YG10X ) | (YL10.2 & WF25) | (Germany K44 &K40) | ( H10F) | |
| Details | Grain size 0.7um | Grain size 0.6um | Grain size 0.5um | Grain size 0.5um |
| Co10% | Co10% | Co12% | Co10% | |
| Flexural strength | Flexural strength 4000N/mm2 | Flexural strength | Flexural strength 4300N/mm2 | |
| 3320N/mm2 | 4300N/mm2 | |||
| Super Coating | |||||
| Coating Classifying and Advantage | |||||
| Item | Coating Type | AlTin | TiAlN | TiSiN | Naco |
| Characteristic | Hardness(HV) | 3300 | 2800 | 4300 | 42(GPA) |
| Thickness(UM) | 2.5-3 | 2.5-3 | 3 | 3 | |
| Oxidation Temp.(°C) | 900 | 800 | 1000 | 1200 | |
| Friction Coefficient | 0.35 | 0.3 | 0.25 | 0.4 | |
| Color | Black | Dark Purple | Copper | Blue | |
| Advantages | High heat stability | Normally cutting | Suitable for heavy cutting, and high hardness cutting | For high precision cutting | |
| Suitable for high speed, dry cutting | Suitable for cutting mould steel, stainless | Suitable for high hardness cutting, mould steel processing | |||
| Most suitable for carbide cutting tools, turning insert | |||||
| Specification | Flute Dia(φ) | Flute Length (C) | Shank Dia(D) | Overall Length(L) |
| Φ1x3Cx4Dx50L | 1 | 3 | 4 | 50 |
| Φ1.5x4Cx4Dx50L | 1.5 | 4 | 4 | 50 |
| Φ2x6Cx4Dx50L | 2 | 6 | 4 | 50 |
| Φ2.5x8Cx4Dx50L | 2.5 | 8 | 4 | 50 |
| Φ3x8Cx4Dx50L | 3 | 8 | 4 | 50 |
| Φ3.5x10Cx4Dx50L | 3.5 | 10 | 4 | 50 |
| Φ4x10Cx4Dx50L | 4 | 10 | 4 | 50 |
| Φ5x13Cx6Dx50L | 5 | 13 | 6 | 50 |
| Φ6x15Cx6Dx50L | 6 | 15 | 6 | 50 |
| Φ8x20Cx8Dx60L | 8 | 20 | 8 | 60 |
| Φ4x20Cx4Dx75L | 4 | 20 | 4 | 75 |
| Φ5x20Cx6Dx75L | 5 | 20 | 6 | 75 |
| Φ6x20Cx6Dx75L | 6 | 20 | 6 | 75 |
| Φ8x25Cx8Dx75L | 8 | 25 | 8 | 75 |
| Φ10x25Cx10Dx75L | 10 | 25 | 10 | 75 |
| Φ12x30Cx12Dx75L | 12 | 30 | 12 | 75 |
|
