Categories | Plastic Poly Bag Making Machine |
---|---|
Model Number: | GFQ-S |
Certification: | CE |
Place of Origin: | China |
MOQ: | 1 set |
Price: | Depends on different model |
Payment Terms: | L/C, T/T |
Supply Ability: | 4 sets / 90 days |
Delivery Time: | 90 days |
Packaging Details: | Without package or wooden |
Cutting Type: | Cold Cutting |
Machine Type: | Forming |
Material: | Poly |
Warranty: | 1 Year |
Approved: | CE, ISO |
Location: | China |
Company Info. |
Kasmac Industries Co., Ltd. |
View Contact Details |
Product List |
Descriptions Of GFQ-S Series :
GFQ-S series used for producing vest bags and flat-opening bags with printing. It is automatically controlled by the computer completely. The main motor is a frequency-conversion motor for higher power efficiency and more freely regulated speed. The excellent color-code tracker achieves more accurate sealing and cutting length and fewer errors. The machine uses an advanced computer to adjust the length more freely and accurately. Double servo step motor fixed length and the liquid crystal touch screen actual display to finish the feeding, sealing, cutting, punching holes and transporting only in one process. It is a high degree automation and good economic model.
Main Technical Parameters | |||
Model | GFQ-S-600 | GFQ-S-700 | GFQ-S-900 |
Bag-making Width | 550 mm | 650 mm | 850 mm |
Bag-making Length | 1600 mm | ||
Bag-making Thickness | 0.008-0.10 mm | 0.008-0.10 mm | 0.01-0.10 mm |
Speed Range | 40-120 pcs/min | ||
Error In Length (mm) | ±1mm | ±1mm | ±1mm |
Main Engine Power | 1.1 | 1.1 | 1.5 |
Total Power | 4 | 4.2 | 5 |
Machine Weight | 700 | 760 | 900 |
Overall Dimension | 3100x1100x1800 | 3100x1200x1800 | 3200x1400x1850 |
![]() |
