Green PVC 2mm Welded Wire Mesh Roll After Electric Galvanized with
3/4" Hole Size
Welded steel bar grating panels are widely used in construction
reinforcement, the ground for the tunnels, bridges, highway,
airport and wharf, also in construction of wall body.
Welded mesh fence panels are utilized as guards in buildings and
factories, as animal enclosure and fence in agriculture; it is also
used in horticulture industry as tree guards, plant protection.
Material:low carbon steel wire, black iron wire,electro galvanized wire, hot
dipped galvanized wire,stainless steel wire, aluminum wire
Width: 0.5m-2.0m
Surface treatment:
* Hot dipped galvanized before welding
* Hot dipped galvanized after welding
* Electro galvanized before welding
* Electro galvanized after welding
* PVC coating after welding
Features:
Galvanized welded wire mesh has the features of excellent
anti-corrosion resistance, acid resistance, anti-alkali property,
oxidation-resistance and excellent flexibility.
Applications:
It is widely used in the industry, agriculture, aquaculture,
building, communication and transportation and mineral extraction,
etc.
Characteristic compared with PVC or Galvanized welded wire mesh:
- Stainless steel welded wire mesh has flat even surface and strong
structure, its high intensity makes it has long service life, even
up to several decades.
- The wire itself has excellent corrosion resistance, acid and alkali
resistance, high temperature resistance, harsh chemicals
resistance, so it can meet your demands of long exposure in
corrosion environment.
- Compared with other material welded wire mesh or PVC-coated welded
iron wire mesh, it is non-toxic, so it can used for food.
- By its very nature stainless steel wire need no additional finish,
such as galvanizing or PVC to protect it, so it can compensate for
its seemingly higher cost.
- Due to this wire mesh panels has beautiful and bright luster, it
looks cleanliness and hygiene, furthermore, this kind of product is
easy to clean.
- Welded wire mesh with strong integration, strong welded points,
well-proportioned meshes, so it has a good strength to hold heavy
weight.
Stainless steel special welded wire mesh in big wire diameter |
Hole Size | Wire diameter | Wide | length |
Inch | mm |
1/4"X1/4" | 6.4mmX6.4mm | 0.7mm | 0.3-2.5m | 10M -30M |
1/4"X1/4" | 6.4mmX6.4mm | 1.2mm | 0.3-2.5m | 10M -30M |
1/4"X1/2" | 6.4mmX12.7mm | 0.9mm | 0.3-2.5m | 10M -30M |
1/4"X1" | 6.4mmX25.4mm | 1.2mm | 0.3-2.5m | 10M -30M |
1/3"X1/3" | 8.5mmX8.5mm | 1.0mm | 0.3-2.5m | 10M -30M |
1/3"X1/3" | 8.5mmX8.5mm | 1.2mm | 0.3-2.5m | 10M -30M |
3/8"X3/8" | 9.5mmX9.5mm | 0.9mm | 0.3-2.5m | 10M -30M |
3/8"X3/8" | 9.5mmX9.5mm | 1.0mm | 0.3-2.5m | 10M -30M |
1/2"X1/2" | 12.7mmx12.7mm | 0.7mm | 0.3-2.5m | 10M -30M |
1/2"X1/2" | 12.7mmx12.7mm | 2.0mm | 0.3-2.5m | 10M -30M |
1/2"X1" | 12.7mmX25.4mm | 2.5mm | 0.3-2.5m | 10M -30M |
3/4"X3/4" | 19mmX19mm | 1.0mm | 0.3-2.5m | 10M -30M |
1"X1" | 25.4mmX25.4mm | 3.0mm | 0.3-2.5m | 10M -30M |
2"X2" | 50mmX50mm | 3.0mm | 0.3-2.5m | 10M -30M |
