| Categories | 4G Mobile DVR |
|---|---|
| Place of Origin: | Guangdong, China (Mainland) |
| Brand Name: | VisionMaster |
| Model Number: | VM-1404-HD |
| Price: | Negotiable |
| MOQ: | 1 Set/Sets |
| Certification: | CE,FCC |
| Payment Terms: | T/T, Western Union,PayPal |
| Supply Ability: | 2000 sets / month |
| Delivery Time: | 3-5 work days for samples,15-30 work days for large orders |
| Packaging Details: | Neutral packing |
| Color: | Black |
| Video input: | 4 AHD + 1 APC |
| Video Compression: | 720P AHD and 1080P/720P IPC POE |
| Storage: | SD card slot * 2 (128GB/SD Card) |
| Function: | WIFI, GPS, 3G, 4G, G-sensor |
| Alarm Input: | 8 Channels |
| Warranty: | 12Months |
| Product name: | 5 Channels Mobile 3G DVR , Real Time Monitoring In Car Multi Camera DVR |
The Five-channel High Definition SD card video recorder is designed for car safety. It uses Linux operating system, combined with video / audio compression / decompression, GPS, car recorder, and the capacity SD card storage technology to confirm the high intelligence and high stability. Widely used for bus, ship, train, and other areas of security.
Specification
Factory directly provide OEM best price 5 channels SD card h 264 dvr connect Vehicle camera real-time monitoring
| Function | Performance | |
| System | Language | English / Chinese |
| Operation Interface | Graphical menu operation interface(OSD menu) | |
| Password security | Permissions setting of administrator & user | |
| Video | Video input | 4 channels support CIF/HD1/D1/960H/720P AHD camera |
| RJ45 X 1, for IP camera or external Wi-Fi module (802.11ac) | ||
| Video output | 2 channels (1 as φ3.5 Phone Jack, 1 at 24pin connector) | |
| Video display | Single picture, 4 pictures | |
| Signal system | PAL / NTSC | |
| Image compression | H.264 Main profile | |
| Audio | Audio input | 4 channels |
| Audio output | 2 channels (1 as φ3.5 Phone Jack, 1 in the 24pin connector) | |
| Record format | Synchronized video & audio recording | |
| Recording& Storage | Video resolution | Support 4 channels CIF/HD1/D1/960H/720P AHD camera Video input Support 4 channels 720P AHD+1 channels IP camera Hybrid HD Video input(Coming in soon) |
| Video coding | ISO14496-10 | |
| Video bit rate | CIF: 1536Kbps ~ 128Kbps, | |
| D1: 2048Kbps ~ 400Kbps, | ||
| 960H: 2048Kbps ~ 400Kbps, | ||
| 8 grades of image quality optional, Grade1 as best, Grade8 as lowest | ||
| Audio bit rate | 8KB/s | |
| Storage | 2 SD card storage optional, up to 128 GB / card | |
| Alarm | Alarm input | 8 channels, alarm activated by low voltage (<1V) or high voltage (>5V) |
| Alarm output | 1 channel, 12V output | |
| Communication Ports | RS485 | RS485 ×1 |
| RS232 | RS232 ×2 | |
| GPS | Built-in GPS module. Real-time geographic coordinates, speed information | |
| G-Sensor | Built-in G-Sensor | |
| Wireless Communication | 3G | Built-in 3G (HSUPA / HSDPA / WCDMA / EVDO / TD-SCDMA) module optional |
| 4G | Built-in 4G(TDD-LTE / FDD-LTE) module optional | |
| Wi-Fi | Built-in Wi-Fi( 2.4 / 5.8 Ghz) optional | |
| Software | PC playback | Video files playback in PC with analysis of the vehicle status |
| CMSV6 / IVMS | Wireless real-time video & audio monitoring, GPS, alarm, etc. | |
| Software Upgrade | Upgrade through SD card | |
|
