300P High Speed Double Twist Bunching Machine For Silver Jacketed Wires

Categories Wire Bunching Machine
Place of Origin: Wuxi Jiangsu China
Brand Name: Newlead
Model Number: 300DTB
Price: Negotiation
MOQ: 1 Set/Sets
Certification: ISO CE
Supply Ability: 10 set in 45 days
Delivery Time: 60 days
Packaging Details: wooden pallet or by wooden box
Usage: Twisting
Name: 300 Bunching machine
Power: 5.5KW motor;5.5KW inverter
Max. rotating speed(RPM): 3500RPM
Wire diameter: 0.05-0.28mm
Stranding section area(mm2): 0.0137-0.45mm2
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

300P High Speed Double Twist Bunching Machine For Silver Jacketed Wires

300 DTB Double Twist wire Bunching machine above 7 pcs ofbare copper wires, tinned wires, silver jacketed wires


Item300
Voltage380V (or according to customer’s requirement)
Power7.5HP motor+7.5HP inverters
Twisting distance(mm)

1.52-16.73

customized


Twisting directionFreedom of choice to left or right
Take-up bobbinФ200-Ф300
Max speed(RPM)4000(or3000)
StrandingSuitable for above 7 wire stranding: copper/silver/alloy/enameled/copper-clad aluminum/copper-clad steel/wick wire
Stranding sec. Area(mm2)0.0137-0.418
Tension controlManual adjustment or magnetic particle auto tracking
Traversing unitFeed rod, traversing/distance adjustable
BrakeElectromagnetic brake
Cut wire controlIn or out cut wire auto brake
Stranding OD(mm)0.05-0.120.5-2.14
Up and down axisManual, electric oil-pressure or mechanical auto up and down
Noise level(db)About 78dbAbout 75dbAbout 78dbAbout 78dbAbout 78dbAbout 78db
PaintApple green (or according to customer’s requirement)
Dimension2300Lx900Wx1050xH2500Lx1200Wx1250xH2600Lx1300Wx1300xH3200Lx1300Wx1500xH3700Lx17000Wx1800xH4100Lx2000Wx2100xH
OilingManual or import auto oiling system, auto enforce oiling

Advantages

1.Over 20 years professional experience.

2.CE,ISO,AAA manufacturer,gold supplier certificate.

3.Machinery are used in over 20 countries,such as India,Egypt,Philippines,Malaysia,Hong Kong,Pakistain,Korea,USA,Germany ect.

4.Has strong technical support,including 3 senior enigneers,8 enigneers and 100 skilled workers.

5.Together with its partners,RBO develops production systems which address all of the needs and preference of wire and cable manufacturers.

6.To offer our customers workshop design.

7.Choose a professional supplier will bring you more convenient.
