Wall Side Container Chassis Trailer 12 Twist Lock White Color Rigid Suspension System

Wall Side Container Chassis Trailer 12 Twist Lock White Color Rigid Suspension System

Description:

• Main Usage

The container trailer focuses on medium and long distance transportation of medium-heavy and heavy cargoes. The wall side trailer is widely used and has strong applicability. Containers and a variety of bulk cargo can be transported.

• Board Structure

The container trailer body is made of high-quality steel with advanced technology and strict production. The trailer has 2 axles with high payload. The loading part of the wall side trailer is the board structure. Frame of the trailer is beam-through structure and is processed by shot-blasting. The vertical beam is designed in flat or gooseneck type.

Advantages:

• Side Opening

5-6 side doors can be equipped in both sides of the trailer. Bolt can be fixed from the exterior or interior. When the vehicle is running, the board can effectively prevent the goods from falling off. The efficiency and safety of transportation is improved.

• Rigid Suspension

Rigid suspension with non-independent steel plate (air suspension is optional) is used. It has strong stiffness and strength to reduce the impact force.

• Customized Design

Trailers are designed and optimized to meet customers’ specific demand by advanced softwares.

Specifications:

Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345; welded by automatic Submerged- Arc processes; Top Flange 14mm, width 140mm; Middle Flange 6mm; Bottom Flange 16mm, width 140mm.
Axle	2 axles
	Brand name: BPW, L1 or FUWA-optional upon choice
Suspension	Mechanical suspension or air suspension
Spring	Leaf spring or air bag
King Pin	JOST brand 2” Bolt-in King Pin
Landing Gear	JOST brand Two-speed, manual operating, heavy duty landing gear
Wheel Rim	8.5-20 ,9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim optional upon choice
Twist Lock	12 no. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container
Tyre	11.00R20 , 12.00R20, 11R22.5,12R22.5,315/80R22.5 tire optional
Spare Tyre	One set of spare tire including a carrier
Braking System	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks
Painting	Complete Chassis sand blasting to clean rust; 1 coat of anticorrosive prime; 2 coats of final paint
Accessories	One standard tool box
