UPoE Cisco 10Gb Network Switch 48 Port WS-C3850-48U-L With 480 Gbps Stack Bandwidth

Categories Cisco 10Gb Ethernet Switch
Brand Name: CISCO
Model Number: WS-C3850-48U-L
Place of Origin: CN/USA/MALAYSIA
MOQ: 1PCS
Payment Terms: T/T, WU, MoneyGram
Supply Ability: 80pcs/week
Delivery Time: 1-3Days
Packaging Details: Double packing for protecting the original box
Price: Negotiable
Feature Set: LAN Base
Available PoE Power: 800W
Package Weight: 17.49 Kg
Product Name: Catalyst 3850 Switch
Input Voltage: 176 Gbps
Switching Capacity: 48
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

UPoE Cisco 10Gb Network Switch 48 Port WS-C3850-48U-L With 480 Gbps Stack Bandwidth

UPoE Cisco 10Gb Network Switch 48 Port WS-C3850-48U-L With 480 Gbps Stack Bandwidth


Cisco next generation Catalyst WS-C3850-48U-L is stackable enterprise level switch and integrated with 48 Ethernet UPOE ports in LAN Base feature set. It offers up to 800W UPOE per switch and 60W per port.

Quick Specs

Table 1 shows the Quick Specs.

Product CodeWS-C3850-48U-L
Enclosure Type1 RU
Feature SetLAN Base
Network SFP uplink module selection

C3850-NM-4-1G

C3850-NM-2-10G

C3850-NM-4-10G

Ports48 x 10/100/1000 ports with UPoE
Available PoE Power800W
Maximum stacking number9
Stack bandwidth480 Gbps
Forwarding Performance130.95 Mpps
Switching Capacity176 Gbps
RAM4 G
Flash Memory2 G
Dimensions44.5 cm x 44.5 cm x 4.45 cm
Package Weight17.49 Kg

Product Details

Figure 1 shows the front panel of WS-C3850-48U-L.

· The switch supports one hot-swappable network module that provides uplink ports to connect to other devices. The switch should only be operated with either a network module or a blank module installed.

Figure 2 shows the back panel of WS-C3850-48U-L.


Note:

Ground connectorStackWise port connector
CONSOLE (RJ-45 console port)StackPower connector
Fan modulePower supply modules
MGMT port

The Modules, Licenses and Accessories

Table 2 shows some modules, licenses and accessories of this switch.

ModelsDescription
C3850-NM-4-1GCisco 3850 Series 4 x 1GE Network Module
C3850-NM-2-10GCisco 3850 Series 2 x 10GE Network Module
C3850-NM-4-10GCisco 3850 Series 4 x 10GE Network Module
L-C3850-48-L-SC3850-48 LAN Base to IP Base Electronic RTU License
L-C3850-48-L-EC3850-48 LAN Base to IP Services Electronic RTU License
PWR-C1-350WACCisco 3850 Series Power Supply 350W AC
PWR-C1-350WAC/2Cisco 3850 Series Secondary Power Supply 350W AC Config 1 Secondary Power Supply
CAB-SPWR-30CM=Catalyst 3750X and 3850 Stack Power Cable 30 CM
CAB-SPWR-150CMCatalyst 3750X and 3850 Stack Power Cable 150 CM
STACK-T1-50CM=Cisco StackWise-480 50cm stacking cable for Cisco Catalyst 3850 series switch
STACK-T1-1M=Cisco StackWise-480 1m stacking cable for Cisco Catalyst 3850 series switch

Compare to Similar Items

Table 3 shows the comparison between WS-C3850-48U-L and WS-C3850-48F-L.

ModelsWS-C3850-48U-LWS-C3850-48F-L
Feature SetLAN BaseLAN Base
Network SFP uplink module

C3850-NM-4-1G

C3850-NM-2-10G

C3850-NM-4-10G

C3850-NM-4-1G

C3850-NM-2-10G

C3850-NM-4-10G

Ports48 * 10/100/1000 Ethernet ports with UPoE48 * 10/100/1000 Ethernet ports with PoE+
Available PoE Power800W800W
