P16mm Outdoor Full Color LED Display With Synchronous / Asynchronous Control

Categories Outdoor LED Display
Brand Name: Vegoo
Model Number: VG-FD P16
Certification: CE/ROHS/FCC/
Place of Origin: China
Supply Ability: 3000Sq.m
Delivery Time: 3-5 days
Packaging Details: Plywood case / Flight case / Carton box
product name: P16 Outdoor Full color LED Display
Pixel Pitch: 16mm
Pixel Configuration: 1R1G1B/DIP 546
Density: 3,906 pixel/m2
Moduel Size(L×W)mm: 256mm×256mm
Cabinet Size(L×W×H)mm: 1024mm×1024mm×130mm
Driving Method: Static
Brightness: 8500cd/㎡
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

P16mm Outdoor Full Color LED Display With Synchronous / Asynchronous Control

P16 Outdoor Full color LED Display HD LED Screen 8500cd/㎡
Description:

1. Multivariate Structural Design:

The cabinets can be installed by ground stacking insallation,column installation,hanging insallation and other insallation,and can also be curved switching to meet the various needs of clients effect.


2. Convenient Maintenance Operations:

Disassembling modules without opening back cover.


3. Reliable Protection Class:

Cabinet's protection grade in front sides and real sides all reach IP65,certified through SGS third party.Screen can be used in wind,rain and snow weather.

P16 Outdoor Full color LED Display Specification

NO:Product NameSpecification
1Pixel Pitch16mm
2Pixel Configuration1R1G1B/DIP 546
3Density3,906 pixel/m2
4Moduel Size(L×W)mm256mm×256mm
5Cabinet Size(L×W×H)mm1024mm×1024mm×130mm
6Module Resolution16×16
7Cabinet Resolution64×64
8Driving MethodStatic
9Driving ICMBI5124
10Brightness8500cd/㎡
11Contrast1000:1
12Brightness AdjustmentAuto and Manual
13Power ConsumptionMax Power: <1200W
14Average power: <550W
15Module Weight0.8kg
16Color Temperature9500K—11500K
17Horizontal Viewing Angle140º
18Vertical Viewing Angle140º
19Signal Processing10 or 14bit
20Grey Processing1024×1024×1024
16834×16834×16834
21Control Distancecable100m,Multimode500m,Single mode 2km
22Frame Frequency65 Hz
23Refresh Rate>1920Hz
24Control ModeSynchronous/Asynchronous
25The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
26Users can choose the recommended curve or adjust it based on actual situation
27MTBF>50000 hours
28Life Span100,000 Hours
29Operating TemperatureWorking : -20 - 65 ℃
30Storage : -40 - 85 ℃
31Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
32Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
34Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
35Power SupplyAC 110-220V
36Protectionwaterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)



Service and Guarantees


Services Before-sale:Set a special telephone line to resolve the confusion from clients and supply free technology services by telephone.Consider the demands of clients carefully , study the situation of the installation condition , Team up the related staff and workers promptly , give clients design program details to help them choose the products which they wanted as soon as possible


Service In - sales :Try the best to meet the reasonable demands by clients Provisional changed .Keep close touch with the clients during the period if installation .Cooperate friendly with the clients, satisfy the clients with the best quality of led display .


Service After-sale:Normal products have one year guarantee, and whole life maintenance, free charges . we just charge materials cost only if products out off guarantee.You can down load and upgrade the related operating software of Led display freely from our company website , so as to resolve the problems when you use our led display .Check the quality of appliance , do maintenance job and ask good suggestions form clients on a regular time schedule .
