wifi data logger, wifi data acquisition data logger

System Feature

• Cortex M3 32-bit ARM
• Reliable performance with built-in double watchdog, 24×7 operation
• Dual digital filters for anti-noise
• Support automatic network reconnection and data re-send
• Synchronize clock with multiple way, Sms, NTP, CwtIO Server
• Automatically execute preset task by schedule(second, minute, day, week, month)
• Support Interlock programming, Event trigger
• Provide configure software, visual programming, over 100 parameters can be set
• Optional exterior rechargable battery for 8-20 hours working when power lost

DI feature

• Accept NO or NC dry contact

DO(T) feature

• Transistor output(drive voltage=power supply voltage, Drive current≤500mA)
• DO can be activated by remote or local schedule
• Remember status when power lost

DO(K) feature

• Relay NO contact output(load: 2A / 125VAC,220VDC)
• on/off/pulse DO by remote control or local event
• Remember status when power lost

AI feature

• Standard 4-20mA (option: 0-5V) signal in, Sampling frequency: 33Hz, 10-bit precision)
• Convert signal to actual measure value,support adjustment
• Support offset and gain, alarm parameters, upload data setting
• Detect connect or disconnect to alarm

SMS feature

• Preset 10 phone numbers (support distribute authority to receive sms)
• Any device alarm status can be sent by sending sms
• Editable alarm and recover sms with time stamp
• Query any IO channel’s status or value via sms command
• Activate output by sending sms
• Configurable schedule for sms report IO channel's status or value
• Remote update parameters by sms
• Forward simcard overdue sms to admin
• Power lost and recover alarm by sending sms

Wireless network communication

• Optianal onboard GPRS, 3g, 4g, Wi-Fi module
• Support TCP/IP two-way communication with Max.4 servers(IP or domain)
• Support post or respond mode for data communication
• Communication protocol: Modbus TCP,http post, Cwt_IO(two-way communication)
• Support two-way data transparent transmission with RS485 or RS232

Modbus feature

• Polling salve over RS485 with modbus rtu protocol
• Can work as a modbus slave to be read/write by master(HMI, SCADA etc.)
• Support Modbus RTU to TCP convert over Ethernet or GPRS/3G

Wireless Remote Monitoring Solutions

Whatever term you use for Telemetry, whether it's remote monitoring, M2M, Machine2Machine, Machine2Man or even Man2Machine then CWT wire free telemetry products will serve you well. Our Telemetry Solutions have been designed with the user in mind, so they are cost-efficient, easy to configure and install.

We can interface to machines in different ways, whether it be via process signals, or serial communications, including Modbus.

Benefits of Telemetry

This ‘Internet of Things’ telemetry technology offers rapid payback, delivering operational, environmental and financial benefits, from cutting delivery miles, to reacting in good time to warnings of machinery breakdown, leakage, theft, run-outs and safety breaches.

Why choose CWT

CWT award-winning Telemetry Solutions are proven globally, in a range of sectors including chemical & petrochemical, food distribution and production, transport, water & waste, environmental and factory automation.
