55m3 LPG Tank Trailer , 12R22.5 Tire 3 Alxe LPG Semi Trailer Air Suspension

Categories Tank Semi Trailer
Brand Name: SINOHTC
Model Number: HTC9501LPG
Certification: CCC
Place of Origin: Qingdao China
MOQ: 1 unit
Price: Negotiation
Payment Terms: Western Union, L/C, T/T, MoneyGram
Supply Ability: 50 UNITS PER MONTH
Delivery Time: 30 DAYS
Packaging Details: Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Tank Material: steel
load: LPG
ABS: fitted
tire: 12R22.5
suspension: air suspension
wheel: 6
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

55m3 LPG Tank Trailer , 12R22.5 Tire 3 Alxe LPG Semi Trailer Air Suspension

50m3 3 alxe Liquified Propane Gas LPG Tanker Semi Trailer / Liquid Petroleum Gas LPG tanker Trailer



Specifications:

Semi trailerTank
Curb weight15300kgDesign pressure1.61Mpa
Payload20832kgDesign temperature-25ºC-50 ºC
G.V.W.36132 kgFilling mediumLPG
Capacity55 m3Tank materialQ345R
Wheel Base6800+1310+1310mmCorrosion allowance1.0 mm
External Dimensions13000*2480*3990mmHydraulic test pressure2.22Mpa
Full loadFifth wheel load16000KgThickness of materialTank12mm
Rear axle load24000kgCover12mm ellipse
Design the limited velocityStraight road80 Km/hVessel's sortThe third kind
Turning20 Km/hService year10 years
Emergence cutting valveSafe valve
Nominal pressurePN2.5MpaModelInner full lift
Nominal diameterGas phaseDN 25mmNominal pressurePN2.5 Mpa
Liquid phaseDN 50mmNominal diameterDN80mm
Operation wayMechanical typeset-pressure1.61 Mpa
Closing time≤10 SecRated relieving pressure<1.93 Mpa
Melt switch temperature70±5ºC
Level meterInlet and outlet
ModelHandle Rotary typeModelQuick tie-in
Nominal pressurePN2.5MpaNominal diameterGas phaseDN25mm
Surveying range50~2300mmLiquid phaseDN50mm
Precision2.5 Grade
Standard configuration3 axles with FUWA bridge (13T),12R22.5 12PR(13 pcs with one spare), JOST 50(2") king pin,JOST leg(25T),mechanic liquid level meters,pressure meter,thermometer,emergency cutting valve ,four ball valve,safe valve,two tool boxes, single outlet ,double loading and unloading system,2 sets 8kg fire extinguishers .

1. This series lpg tank semi trailer applicable for the transportations of the liquified petroleum gas, anhydrous ammonia, propone and other liquid gas.

2. The capacity is for 30tons , we can manufacture it according to your needs.

3. The axles can be Fuwa / Bpw with different tonnages by your need with price differences.
4. The suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension

5. Creative design for your own special transportation program.

6. High tensile steel provides the strongest performance of semi trailer.

7. Automatic submerged arc welding and straightening machines make best main beam.

8. One coat blasting plus two coats polyester painting.

9. Standard and Brands of semi trailer parts can be chosen according to different requests.

10. Necessary accessories offered.
