Waterproof RG6 RG59 RG58 Coaxial Cable Compression BNC Connector For RF

Categories Coaxial TV Cable
Brand Name: OEM/ ODM/ Lansan
Model Number: BNC Connector
Certification: CE/ RoHS/ ETL/ ISO
Place of Origin: China
MOQ: 1000 pcs
Price: Negotiation
Payment Terms: L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability: 10000 Meters/ Day
Delivery Time: 5-7 Work Days
Packaging Details: 100pcs / bag
Type: BNC Type Connector
Applicaiton: RF
Plating: Nickel
Fastening Type: Snap-On
Medium Pressure: 1500V
Applicable Standard: IEC 60169-24
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Waterproof RG6 RG59 RG58 Coaxial Cable Compression BNC Connector For RF

Waterproof Compression BNC Connector for RG58 RG59 RG6 Coaxial Cable


Parameter


Characteristic Impedance75ohm
Frequency RangeDC-4GHz
VSWR≤1.30@DC-1000MHz
Insertion Losss≤0.2dB
Working Vlotage500V RMS,50Hz,at sea level
Dielectric Withstanding Voltage≥1500V RMS,50Hz,at sea level
Dielectric Resistance≥5000MΩ
Contact ResistanceCenter Contact ≤1.5mΩOuter Contact ≤1.0 mΩ
DurabilityMating cycles ≥500
Parts NameMaterialPlating
BodyBrassNi
InsulatorPTFE-
Inner ConductorPhosphor BronzeAu
Coupling NutBrassNi
GasketSilicone Rubber-
FerruleAnnealed CopperNi
Operating Temperature_45 °C~-85 °C
Weatherproof RateIP67
RoHs (2002/95/EC)Compliant by exemption

Specificaiton


  • Body material:Zinc Alloy and Nickel plated
  • Pin material:Brass and gold plated
  • Insulating material:PE
  • Silicone O-ring sealed ,watertight
  • Length:61mm, weight:13.5g
  • Carton size:34*24*20cm
