CD11HPT Small Wireless Drone Video Transmitter , HD Sender Receiver With TTL Serial Port

Categories DMR Two Way Radio
Model Number: CD11HPT
Place of Origin: Shenzhen, China
Brand Name: SUNTOR
Certification: FCC, CE, RoHS
MOQ: 1 set
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000 set/ month
Delivery Time: 7-15 days
Price: Negotiation
Packaging Details: Plastic Box
modulation: COFDM
Working Frequency: 2.402-2.478GHz adjustable
Transmission Distance: Air to ground 10km
Transmission Power: 1W
resolution: HD 1080P
Video input: High Definition Multimedia Interface and Ethernet
small size: 72×47x19mm
light weight: Tx:94g Rx: 98g
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

CD11HPT Small Wireless Drone Video Transmitter , HD Sender Receiver With TTL Serial Port

RF1W HD 1080P Wireless Drone Video and Data Sender Receiver with TTL Serial port


CD11HPT Drone Video Transmitter & Receiver Specifi...


Description


CD11HPT is a mini HD Video and Data transmission COFDM system for UAV. It develops CABAC (h.264) coding&decoding technology to achieve Utra-high resolution(1080P), long distance(air to ground 10km) and low delay(12-25ms) transmission. The system supports two-way(data&image) communication, adjustable video resolution, bit rate output with the TPlayer software. It can realize the soft decoding with low delay. Meanwhile this SUNTOR series products have small size, light-weight, low consumption, high stability and high sensitivity. They are suitable various environment of different application.


Features:

  • Zero delay videos wireless transfers prototypes
  • Diffraction & through-wall ~ support point to point, point to multipoint
  • Two way image & data & voice transmission
  • Small size, low consumption, high/low temperature resistance (industrial level)
  • Support the High Definition Multimedia Interface input/output and SBUS, PPM, TTL
  • Support image transmission & data transmission , combined multiple radio links
  • Support 100Mbps Ethernet to output
  • 1080P/300 meters altitude up to 10 km transmission distance
  • The video is clear and stable, has no mosaic or drag phenomenon.

Suntor’s HPT Series tiny video transmitters offer many innovative features, are designed to withstand harsh environments, and are ideal for Drones, UAV, and other applications requiring high efficient, high quality video/data transmission in a compact, rugged package.


HPT transmitters may be configured with fixed RF output powers of 400 mW, 1 Watt, or 1.5 Watts. Transmitters may be optionally configured with remotely selectable power levels utilizing any of these three power levels. Suntor’s proprietary power-leveling circuit ensures level output power over the entire frequency band.


Application



Parameters

ModulationCOFDM
Dimensions72×47x19mm (antenna not included)
Net WeightTx:94g Rx: 98g (antenna not included)
Transmission DistanceAir to ground 10km
Working Frequency2.402-2.478GHz adjustable
Transmission Power1W (30dBm)
RF Bandwidth2/8/20MHz
Transmission Modepoint to point / point to multipoint
Video Color SpaceDefault 4:2:0 optional: 4:2:2/4:4:4
Video Compressed FormatH.264 TS
Video inputHigh Definition Multimedia Interface / Ethernet
ResolutionFull HD 1080P
InterfacePower input interface × 1
Antenna interface × 1
RS232 Bidirectional Port × 1
Ethernet to USB / RJ45 on Windows × 1
Two-way functionIntegrate multiple radio links, SBUS/PPM/TTLS 1 pro communication module
Adjustment mode of bit rateSoftware adjustment
Communication Channel EncryptionWEP, WPA(PSK), WPA2(PSK), WPA+WPA2 (PSK), AES 125/256
Working Temperature-40°C - 85°C
Working VoltageDC7~18V Optional
Power Consumption

TX: 7Watts

RX: 5Watts

Start-up time< 30s
System Latency≤50ms
