Categories | PCB Terminal Block |
---|---|
Brand Name: | HQ |
Model Number: | HQ211R-2.54 |
Certification: | UL, ROHS |
Place of Origin: | CHINA |
MOQ: | 100PCS |
Price: | USD 0.1-0.5 PER PIECE |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000PCS PER DAY |
Delivery Time: | 0-3 DAYS |
Packaging Details: | export paper carton |
Number of Contacts: | 1P*XXP |
Conductor Size: | 26~18AWG |
Type: | Spring |
Delivery Detail: | Shipped in 3 days after payment |
HQ211R-2.54 2.54mm Pitch RA Screwless Connector PCB Terminal Block PA66 UL94V-0 For Light
Plastic material: PA66 UL94V-0 |
Pin header: Brass,Tin plated |
Clamp: Steel |
UL |
Rated voltage: 150V |
Rated current: 5A |
Wire range: 26-18 AWG |
Withstanding voltage: AC1500V/1Min |
Temp.: -40℃ ~ +105℃ |
Max soldering: 250℃±10℃/5Sec |
Strip length: 12mm |
Pitch: 2.54mm |
Pole: 1-XXP |
If you do not find the exact items your needs pls feel free to contact us. And kindly give us the picture, item NO. or drawing,so we can give you our best resolves,thanks.
![]() |
