Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips

Simple Steel Coil Slitting Cutting Machine for Slitting Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips

A). Introduction

1. This line includes Uncoiler, Feeding Guide, Slitting Machine, Cantilevering Separating, Tension Control Board, Console and General electrical equipment.
2. Electrical Source: 380V/50Hz/3Ph ( or depend on local requirement )
3. Speed of line: 0-40m/min.
4. Main power: 48 KW
5. Floor Area accupied by machine: 10m (L) x 3m ( Width )
6. Production operation: 1 Skilled Worker, 1 common worker

B). Main Components

1. Hydraulic Decoiler -------------------------------------------------- 1 Unit
2. Leveling and Feeding Guide ------------------------------------- 1 Unit
3. Slitting Machine ----------------------------------------------------- 1 Unit
4. Cantilevering Separating ------------------------------------------ 1 Unit
5. Tension Control Board --------------------------------------------- 1 Unit
6. Console --------------------------------------------------------------- 1 Unit
7. General electrical equipment ------------------------------------- 1 Unit

C). Main Specification

1. Material: Carbon steel, GI, Color steel – Q235-Q350
2. Thickness: 0.2-2.0mm
3. Width: 400-1300mm
4. Inner diameter of coil: φ450—φ510
5. Outer diameter of coil: φ1500mm. Max.
6. Weight of coil: 5 Ton. Max.
7. Diameter of slitting blades: φ120
8. Material of slitting blades: 40Cr

D). Finished Products Data

1. Tolerance of width: ≤±0.02mm
2. Max. strips to be slited: 10 pieces
3. Min. width of the pieces: 50mm

E). Applications

F). Competitive Advantages

• High Quality
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience
• Professional Team Support

G). Reference Pictures

Wuxi Techwell Machinery Co.,Ltd is a professional manufacturer specializing in the developing and exporting of cold roll forming machines and insulated sandwich panel machines and Slitting cutting machines.

Roll Forming Machines: Metal roof & wall panel roll forming machine, steel tile roll forming machine, dual level roll forming machine, C/Z/U/L shaped steel roll forming machine, drywall stud and track roll forming machine, steel floor deck roll forming machine, highway guardrail roll froming machinem downspout roll forming machine, rainwater gutter roll forming machine, portable downspout / gutter machines, door frame roll forming machine, roller shutter door roll forming machine, no-girder k span arched panel roll forming machine, slitting & cutting, roof curving machine, stacker machine and so on.

Insulated Sandwich Panel Machines: PU sandwich panel machine, rubber belt pu sandwich panel machine, continuous pu sandwich panel machine, EPS sandwich panel machine, rockwool sandwich panel machine, eps & rockwool sandwich panel machine, mineral wool sandwich panel machine and so on.

Wuxi Techwell engaged in the steel structure industry in many years and devoted to developing some steel structure machines with a professional technology and reasonable price, we supply the best machines for our new and old customers. In paticular, we are a leading exporter in the field of steel structure construction, and can provide professional service, high quality, through design and installation. Our goal is " Future by heartiness, faith leads to the world".

Warmly welcome to visit our factory and we are looking forward to cooperating with you for mutual benefits.
