2 Component Thermal Conductive Silicone Potting Compound Adhesive Liquid Gel

Rtv Silicone Two Component Thermal Conductive Adhesive Waterproof Low Viscosity Waterproof Sealing High Moisture Resistance Glue

HN-8806 Two-Component Addition-Type Silicone Potting Rubber

Product Specification

Product Advantages

High-Performance Elastomer: Forms a high-elasticity, high-strength protective layer after curing.

Low Viscosity: Suitable for deep-section potting, ensuring even distribution.

No By-Products: No heat or by-products are emitted during curing, ensuring component safety.

Flame Retardant: Passes UL-94 flame retardancy tests, ensuring safety in high-temperature environments.

Eco-Friendly Certification: Complies with RoHS standards, non-polluting.

Applications

Potting and sealing of power modules, circuit boards, and high-voltage transformers.

Protection and thermal management for battery packs and fast-charging adapters.

Moisture-proof and waterproof protection for LED outdoor drive power supplies.

Other electronic components requiring vibration, water, and thermal protection.

Application Method

1.Mix components A and B in a 1:1 ratio, stir thoroughly, and then proceed with potting.

2.Ensure the surface of the components is clean before potting. For large products, pot in stages.

3.For automated production lines, vacuum components A and B separately to ensure accurate mixing ratio.

Technical Parameters

Appearance: Part A – Grey fluid; Part B – White fluid

Viscosity: 4500~5000 mPa·S

Density: 1.50±0.05 g/cm³

Mixing Ratio (A:B): 1:1

Pot Life: 0.3-0.4 hours

Curing Conditions: 4-12 hours at room temperature (initial cure), 0.2 hours at 80°C

Hardness: 50±5 Shore A

Thermal Conductivity: ≥0.76 W/m·K

Volume Resistivity: 1.0×10¹⁵ Ω·cm

Temperature Resistance: -50°C to +250°C

Packaging
10KG/Set (A 5kg + B 5kg)
20KG/Set (A 10kg + B 10kg)
50KG/Set (A 25kg + B 25kg)

Precautions

Stir components A and B separately before use to ensure even mixing.

Avoid contact with substances containing tin, sulfur, or amines to prevent curing inhibition.

Maintain cleanliness during use to prevent contamination.

Shenzhen Hanaste New Materials Co., Ltd. is a subsidiary of Shenzhen Kanglibang Technology Co., Ltd. The brand "Hanast", established in 2019, has been dedicated to expanding the international market. The company is committed to the research and development and innovation of new adhesive materials, integrating R&D, manufacturing, sales and service. It has developed into a national "Little Giant" enterprise specializing in "Specialized, Precision, Unique and Innovative" and a national high-tech enterprise. With a modern production base of 40,000 square meters, the company has become a professional service provider for one-stop customized packaging and heat dissipation material solutions through its independent R&D and production capabilities.

The company has been awarded multiple national invention patents and utility model patents. Its core product, "silicone pressure-sensitive adhesive", has been recognized as a "Guangdong Province Famous and High-tech Product".

Relying on the strong technical strength of Kanglibang, the company has gathered a group of high-quality scientific research talents and a technical team with over ten years of practical experience. The products are deeply trusted by customers and have established cooperative relationships with many world-renowned enterprises such as ABB, Apple, Google, China Southern Power Grid, Foxconn, ZTE, BYD, and Wolong Nuclear Materials. The company's products comply with ROHS standards and have passed authoritative certifications such as SGS, FDA, LFGB, and China Environmental Label.
