Name: 6015 CNC Tube Laser Cutter Pipe Fiber Laser Cutting Machine For Pipe Cutting t
Brand: GONXING
Price: 36 USD

Home > Holiday Lighting >

6015 CNC Tube Laser Cutter Pipe Fiber Laser Cutting Machine For Pipe Cutting t

Categories	Fiber Laser Cutting Machine
Place of Origin:	Shandong, China
Brand Name:	GONXING
Price:	$36,500.00/sets 1-9 sets
Application:	LASER CUTTING
Applicable Material:	metal, Metal, Metal Sheet and tube
Condition:	New
Laser Type:	Fiber Laser
Cutting Area:	1500mm*3000mm
Graphic Format Supported:	AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP, Dwg, DXF, DXP
Cutting Thickness:	30mm
CNC or Not:	Yes
Cooling Mode:	WATER COOLING
Control Software:	Cypcut
Laser Source Brand:	MAX/Raycus/IPG
Laser Head Brand:	Raytools
Servo Motor Brand:	Yaskawa
Guiderail Brand:	HIWIN
Control System Brand:	Cypcut, Cypcut
Weight (KG):	5000 KG
Key Selling Points:	Competitive Price
Warranty:	3 years
Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Printing Shops, Construction works , Energy & Mining, Other, Advertising Company
Machinery Test Report:	Provided
Video outgoing-inspection:	Provided
Warranty of core components:	3 years
Core Components:	Pressure vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC, rail, laser source, laser head, water chiller
Mode of Operation:	continuous wave
Configuration:	5-axis
Products handled:	Tube
Feature:	Water-cooled
Reducer:	SHIMPO/Motovairo
Electrical components:	Schneider made in France
processing precision:	≤0.1mm
Max. linkage speed:	91m/min
Positioning accuracy:	0.05mm
Repositioning accuracy:	0.03mm
Automatic focusing function:	yes
MOQ:	1 set
Payment Terms:	T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow

Contact Now

Add to Cart

Company Info.

Shandong Gonxing Laser Cnc Machinery Co., Ltd.

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

6015 CNC Tube Laser Cutter Pipe Fiber Laser Cutting Machine For Pipe Cutting t

model	GX-6012T	GX-6017T	GX-6024T	GX-6029T	GX-6035T
working area	1500*3000mm	1500*4000mm	1500*6000mm	2000*4000mm	2000*6000mm
X/Y axis positioning accuracy	±0.03mm
X/Y axis repositioning accuracy	±0.01 mm
maximum movement speed	120 m/min
maximum acceleration	1.5G
Laser Power	1.5-6kw	1.5-6kw	1.5-6kw	1.5-6kw	1.5-6kw
Laser Source	MAX/RAYCUS/IPG(optional)					1.5G	1.5G	1.5G
laser cutting head	OSPRI/ PRECITEC/ RAYTOOLS (optional)
servo motor	Fuji/Delta/INOVANCE/Yaskawa (optional)
systems & software	CYPCUT
Reducer	Shimpo

Auto focus laser head specail cutting tube

recitec or Raytools auto-focus laser head,World brand and quality.
The software automatically adjusts the focal length to complete rapid perforation and cutting of sheets of different thicknesses.
It is more friendly to those with 0 experience, and the operation is simple, convenient, fast and accurate.

High quality Servo motor and Driver

With their high efficiency and high power factor, Fuji Electric's Medium-voltage inverters contribute significantly to cost
reduction and energy conservation.
Our inverter products are applicable in a wide range of fields from plants to general industry and feature superior ease of
maintenance.

High quality fully pneumatic chuck

Full-stroke pneumatic chuck with a built-in cylinder, which is easy to install. The clamping and loosening actions are realized by air intake from the side. It can clamp a full range of applicable pipe fittings and has a full stroke to improve production efficiency.

The four-claw guide uses a guide rail mechanism to drive, making the four-claws more linear and stable, achieving a self-centering effect. There is no need to additionally adjust the position of the four-claws, which greatly reduces the labor cost of machine adjustment and improves production efficiency. Uploading... rate.

Aviation Aluminum Beam

The beam is made of aviation-grade extruded aluminum, which has the advantages of good toughness, light weight, corrosion
resistance, oxidation resistance, low density, etc. It also has excellent dynamic performance, which is conducive to high-speed
cutting.

Accuracy measurement

Original 35mm Taiwan YYC rack, Hiwin guide rail.Greater carrying capacity to the thickness of the metal to be cut.and with Automatic lubrication system it can help the users more convenient and save more time .

Detailed control

Whole machine delivery, no installation is required, and it is ready to use when plugged in.

Industrial computer, good cooling
effect, dustproof.

Testing made before shipment.

each customers machine all be tested and runing more than 24h in our factory and testing kind of materails and thickness and save the parameters for all of the customers .

High quality accessories guaranteed

with top brand Raycus Auto focus laser head. it is more convenient for without any using experience customers to make adjustments .and long using life

Quality control

Ensure the accuracy of cutting parameters and ensure high-quality cutting samples.it will be more stable for customer working

Q: What is a fiber laser cutting machine? A: Fiber laser is a special type of solid laser. Typically, fiber lasers are optically pumped, which is accomplished by coupling the radiation from a diode maser or other fiber laser into the cladding or core itself in a direction parallel to the fiber core. In many cases, to achieve higher output power, double-clad fiber is used. What materials can fiber laser cut? Various metals such as stainless steel, carbon steel, mild steel, galvanized steel, aluminum,Copper etc. Q: Do you have CE documents and other customs declaration documents? A: Yes, we have the original. First, we will show you and give you CE/packing list/commercial Invoice/sales contract for customs clearance. Q: Payment terms? A: Alibaba Trade Assurance/TT/Western Union/Payple/LC/Cash, etc. Q: I don’t know how to use it after receiving it, or I encounter problems during use. What should I do? A: We can provide cam for team viewer/Whatsapp/email/phone/Skype until you solve all the problems. Q: What is your MOQ? A: We have no MOQ. Whether it is an order for 1 set or 100 sets, we will support you wholeheartedly. Q: How does your factory do in terms of quality control? A: Quality is priority. Each OREE laser machine will undergo 24 tests. After all 24 items are passed, our QC will conduct a 48 to 72 hours reliability test. Our laser machine has obtained CE.
